Specifications
Low starting torque 2years warrantyHigh generating efficiency
Large power, low volume
CE RoHS ISO
15 Years life span
CE 400w wind solar hybrid controller+400W windmill wind turbine
Product Characteristics:
1. Large power, low volume, low weight, high efficiency
2. Carbon fiber blades, high efficiency of anti-wind ability
3. Blades with the ability of automatically stall protection under strong wind
400w wind solar hybrid controller;
1.The controller can connect with solar panel no more than 300w.
2.If you want to connect with s solar panel more than 300w,please Tell us in advance.
Product Specification:
Wind generator |
Model |
Z-400W |
Z-600W |
|||
Wind turbine Name |
City Swallow |
City Swallow |
||||
Rated power |
400W |
600W |
||||
Rated DC voltage |
DC 12V/24V |
DC 12v/24v/48v |
||||
Rated current |
33A/17A |
50A/25A/12.5A |
||||
Rated speed |
740r/m |
640r/m |
||||
Max power |
460W |
680W |
||||
Number of blade |
3 pcs |
5 pcs |
|
5 pcs |
||
Starting wind speed |
3m/s |
2.5m/s |
|
2.5m/s |
||
Cut-in wind speed |
3.5m/s |
3m/s |
|
3m/s |
||
Cut-out wind speed |
15m/s |
15m/s |
||||
Security wind speed |
45m/s |
45m/s |
||||
Rated wind speed |
12m/s |
12m/s |
||||
Engine |
Three-phase permanent magnel generator(USD200) |
Three-phase permanent magnel generator(USD285) |
||||
Rotor diameter |
1450mm |
1850mm |
||||
Blade material |
Carbon fiber reinforced plastics |
Carbon fiber reinforced plastics |
||||
Output line anti-winding device |
Over all three-phase commutator |
Over all three-phase commutator |
||||
Over-speed wind protection |
Tip stall protection + turned protection + Electromagnetic brake |
Tip stall protection + turned protection + Electromagnetic brake |
||||
Life span |
15 years |
15 years |
||||
Equipment surface protection |
Aluminum oxide + plastic coating |
Aluminum oxide + plastic coating |
||||
Working temperature |
-40°C-70°C |
-45°C-70°C |
||||
N.W. |
14.5kg |
15.3kg |
|
19.9kg |
||
Packing material |
Carton box and foam material |
Carton box and foam material |
||||
packing dimension |
980*460*245mm |
980*460*245mm |
||||
G.W. |
15.5kg |
16.3kg |
|
22.1kg |
||
Wind-solar controller Technical parameters
Type |
LDK-3-600/150-12/24 |
|
System rated voltage |
12V/24V |
|
Solar/PV module power |
120-720W |
|
Wind turbine power |
3-600W |
|
Charging |
Charging |
20A-50A(wind) 10A-30A(solar) |
Equalize Protection |
14.4V±1% 28.8V±1% |
|
Float charge |
13.8V±1% 27.6V±1% |
|
Equalize recovery |
13.2V±1% 26.4V±1% |
|
Over discharge |
Disconnect (DC) |
10.9V±1% 21.8V±1% |
Restoration (DC) |
12.3V±1% 24.6V±1% |
|
Overvoltage |
Cut off (DC) |
16V±1% 32V±1% |
Restoration (DC) |
15V±1% 30V±1% |
|
Load Current(DC) |
≤0.06A |
|
Voltage drop(DC) |
≤0.5V |
|
Control mode |
Dual maximum power point tracking-MPPT (PWM charging efficiency 20% higher than ordinary type) |
|
Display mode |
Digital tube and LED |
|
Display Parameters |
Battery power, the load output |
|
Type of protection |
Solar reverse charge protection, battery open-circuit protection, reverse battery protection, over-speed and over-voltage protection soft automatic braking |
|
Heat dissipation |
Heat sink |
|
Ambient temperature |
-25°C~+55°C |
|
Use altitude |
≤4000m(>2000m need to reduce power usage) |
|
Humidity |
0~90%, No condensation |
|
Net weight |
880/1080g |
|
size |
Length 125 /175* width 151 * high 66(mm) |
|
