HY-B Semi automatic suppository package machine
Working principle
Rolls of Packing film (PVC PVC / PE, dual aluminum composite film) will be send to filling process after shell making, and the liquid medicine will be filling into empty suppository shell automatically through the high precision metering pumps. Then it will be a suppository line and cuts into sections automatically according to the length of the suppository line. And conveyed to cooling devices to make it cool and be solidification. After that it will be filling, truing, printing date of production and molding.
Main technical parameter:
Model |
Unit |
HY-B Semi-automatic Suppository Production Machine |
Capacity |
PCS/Hour |
5000-10000 |
Single dosage |
ML |
0.5~5 (depending on product) |
Deviation |
% |
<±2% |
Suppository shape |
N/A |
Bullet, torpedo, duck-mouth ect(depending on product) |
Adapting |
N/A |
Fatty acid glycerin,gelatin,glycol,etc., (depending on product) |
Volume |
L |
50 |
Air pressure |
Mpa |
0.6 |
Air consumption |
m3 |
1.5 |
Water consumption |
N/A |
50kg per circle |
Voltage, frequency |
V |
3PH 380 +/-10% 50Hz |
Total Power |
KW |
5Kw |
Package film |
|
PVC,PVCPE |
Total weight |
KG |
700 |
Machine dimensions |
MM |
5155*1640*1879mm |
Advantage of our machine:
1.PLC detection function: Through PLC on-line detection function, it can do the self-checking alarm especially for the operation fault.And it can also display the fault reason synchronously, it is easy for the operator to do timely fault removing.
2.The suppository cutting quantity adjustable system.
Remarks: The quantity can be setup as 4/5/6/7 pieces per time for the final product.
3. Stable operation and low failure rate.
Machine and sample pictures:
