Suppository Production Line
US$ 60,000 - 70,000
/ Set
1 Set(Min. Order)
- Shanghai
You May Like
Product Details
| Condition | New | Place of Origin | Shanghai, China | |
| Brand Name | Hongyuan | Model Number | HY-U | |
| Usage | Other, suppository | Voltage | 380V.50HZ | |
| Power(W) | 7.5KW | Weight | 2000kg | |
| Dimension(L*W*H) | 3100*3480*2000mm | Certification | CE | |
| Warranty | one year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Suppository production line
Specifications
The design is novel, the operation is simple, is a highly efficient and stable production unit of automatic suppositories.
Working principle:
Working principle:
Rolls of Packing film (PVC PVC / PE, dual aluminum composite film) will be send to filling process after shell making, and the liquid medicine will be filling into empty suppository shell automatically through the high precision metering pumps. Then it will be a suppository line and cuts into sections automatically according to the length of the suppository line. And conveyed to cooling devices to make it cool and be solidification. After that it will be filling, truing, printing date of production and molding.
Technical Parameters:
| Output | 8000-12000 granule/h | |||
| Single dosage | 0.5-5ml | |||
| Dosage allowed | <±2% | |||
| Form | Bullet, Torpedo,Duckbilled and other shape | |||
| Adapt to the host | Synthcticfat glyceric acid,glyceride,glycerin gelatine,polyethyleneglycol and so on | |||
| Store the capacity of the liquid barrel | 50L | |||
| Atmospheric pressure | 0.6MPa | |||
| Consume the tolerance | 1.5m3 | |||
| Water quantity | 800kg(cycled using) | |||
| The voltage of the power | 380v | |||
| Total power | 7.5kw | |||
| External dimension | 3470x3480x2230mm | |||
| Total weight | 2000kg | |||
