4.5/5kva Single Cylinder Air Cooled 4 Stroke Diesel Generator KDE6500E
Specifications
1.100% copper wire2.Factory directly provided
3.CE & ISO approved
4.Do what you need
GENERATOR |
Model |
KDE6500E |
|
Frequency:Hz |
50 |
60 |
|
Rated output:Kva |
4.5 |
5 |
|
Max.output:Kva |
5 |
5.5 |
|
Rated.AC voltage:V |
115/230 |
120/240 |
|
Current:A |
39.1/19.6 |
41.7/20.8 |
|
Phase |
sigle-phase |
||
DC output: |
12V/8.3A |
||
Power factor(cosφ) |
1 |
||
Alternator type |
self-excited,2-pole,single phase alternator |
||
Starting system |
Electric Start |
||
Operatong noise lecel(at 7m):dB(A) |
E:77 |
||
Fuel tank capacity:L |
E:12.5 |
||
ENGINE |
Model |
KA186FA |
|
Type |
Single-cylinder,vertical,4-stroke air-cooled diesel engine |
||
Bore × Stroke(mm) |
86×72 |
||
Fuel |
Summer:0# Winter: -10# |
||
Lubricatiom oil Model: |
SAE10W-30(above CD grade) |
||
Lubricatiom oil volume:L |
1.65 |
||
Fuel comsumption Rate(g.kw/h) |
275.1 |
281.5 |
|
Displacement:L |
0.418 |
||
Power/speed:KW, r/min |
5.7/3000 |
6.3/3600 |
|
Compression Ratio |
19 |
||
Combustion system |
Direct lnjection |
||
STANDARD FEATURES |
Voltmeter |
Yes |
|
AC Output Socket |
2 |
||
AC circuit breaker |
Yes |
||
Oil warning light |
Yes |
||
Oil alert |
Yes |
||
OPTIONAL FEATURES |
DC circuit breaker |
Optional |
|
Calculagraph |
Optional |
||
Big Wheel |
Optional |
||
Current meter |
Optional |
||
ATS |
Optional |
||
AMF Digital Panel |
Optional |
||
Remote control |
Optional |
||
DIMENSIONS |
Structure: |
Open-frame |
|
Dimension:mm |
760*515*710 |
||
Dry weight:kg |
97 |
||
20FT |
99 |
||
