Help CenterKDE6500EW
US$ 605 - 615
MOQ: 5 Sets
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
KAIAO
Model Number:
KDE6500EW
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Jiangsu, China
Brand Name
KAIAO
Model Number
KDE6500EW
Output Type
AC Single Phase
Speed
3000/3600rpm
Frequency
50HZ
Rated Power
2KW
Rated Voltage
230V
Rated Current
8.7A
Specifications
1.Factory directly supply2.CE&ISO9001 Certificated
3.Various kinds&accept OEM design
4. Aviation Technology,Military Quality
| Model | KDE6500EW |
| Frequency:Hz | 50HZ |
| Rated output:Kva | 2KVA |
| Rated.AC voltage:V | 230V |
| current:A | 8.7A |
| No-load welding voltaged:V | 65V |
| Rated welding voltaged:V | 26--30V |
| Rated welding DC:A | 200A |
| Current adjusting extension | 50--200A |
| Electric welding load rate | 50% |
| Phase | Single phase |
| Power factor:COS | COS=1 |
| Alternator type | self excited,2 pole,single phase alternator |
| Starting system: | X:Recoil Starter E/T:Electric Starter |
| Operatong noise lecel(at 7m):dB(A) | X/E:77 T:72 |
| Fuel tank capacity(L):L | X/E:12.5 T:15 |
| Model | KA186FA |
| Engine type | Single-cylinder,vertical,4-stroke air-cooled diesel engine |
| Bore × Stroke:(mm) | 86×72mm |
| Fuel | Summer:0# Winter: -10# |
| Lubricatiom oil Model | SAE10W-30(above CD grade) |
| Lubricatiom oil volume:L | 1.65L |
| Fuel comsumption Rate(g.kw/h) | 275.1 |
| Displacement:L | 0.418 |
| Power/speed:KW, r/min | 5.7KW/3000rpm |
| Compression Ratio | 19 |
| Combustion system | Direct lnjection |
| Dimension(L*w*h) | 640*480*530mm |
| net weight | 105kg |
