KDE6700EW
Specifications
1.CE&ISO9001 Certificated2.Low noisely
3.Air-cooled diesel engine
4.Rate power:200A,50/60HZ, 2.0/2.2KW
5.Single Phase
| GENERATOR /WELDER | Model | KDE6700EW |
| Frequency:Hz | 50HZ | |
| Rated output:Kva | 2KVA | |
| Rated.AC voltage:V | 230V | |
| current:A | 8.7A | |
| No-load welding voltaged:V | 65V | |
| Rated welding voltaged:V | 26--30V | |
| Rated welding DC:A | 200A | |
| Current adjusting extension | 50--200A | |
| Electric welding load rate | 50% | |
| Phase | Single phase | |
| Power factor:COS | COS=1 | |
| Alternator type | self excited,2 pole,single phase alternator | |
| Starting system: | X:Recoil Starter E/T:Electric Starter | |
| Operatong noise lecel(at 7m):dB(A) | X/E:77 T:72 | |
| Fuel tank capacity(L):L | X/E:12.5 T:15 | |
| ENGINE | Model | KA186FA |
| Engine type | Single-cylinder,vertical,4-stroke air-cooled diesel engine | |
| Bore × Stroke:(mm) | 86×72mm | |
| Fuel | Summer:0# Winter: -10# | |
| Lubricatiom oil Model | SAE10W-30(above CD grade) | |
| Lubricatiom oil volume:L | 1.65 | |
| Fuel comsumption Rate(g.kw/h) | 275.1 | |
| Displacement:L | 0.418 | |
| Power/speed:KW, r/min | 5.7KW/3000rpm | |
| Compression Ratio | 19 | |
| Combustion system | Direct lnjection | |
| Dimension(L*w*h) | 640*480*530mm | |
| net weight | 105kg |
