KDE6500EW Double Use 2kw Welding Generator 200A Current 3kw Welding Generator 300a Cureent

Name: KDE6500EW Double Use 2kw Welding Generator 200A Current 3kw Welding Generator 300a Cureent
Brand: Kaiao
SKU: 104347323

US$ 585 - 630 MOQ: 5 Sets

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

Kaiao

Model Number:

KDE6500EW

Wuxi Kaiao Power Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name Kaiao

Model Number KDE6500EW

Output Type AC Single Phase

Speed 3000/3600

Frequency 50/60

Rated Power 2kw

Rated Voltage 230 / 240v

Rated Current 50-200A

Specifications

1.Factory directly supply
2.CE&ISO9001 approved
3.Various kinds&accept OEM design
4.Aviation Technology,Military Quality

Diesel generator KDE6500EW
Model	KDE6500EW
Frequency(HZ)	50	60
Ourput power(kVA)	2	2.2
Voltage(V)	230	240
Current(A)	8.7	9.2
No-load welding voltage(V)	65
Rated welding voltage V	26-30
Rated welding DC A	200
Current adjusting extension A	50-200
Electric welding load rate	50%
Speed(r/min)	3000	3600
Phase	Single
Power factor(cosφ)	1
Excitation system	Self-excited constant voltage
Noise level(7m)	DB (A): 77
Fuel tank capacity(L)	12.5
Structure	Open-frame
Panel	Ordinary
Output socket	Two
Output terminal post	Two
Net weight(kg)	126
Dimension(LWH)mm	760515710
Engine model	KA186FA
Bore*stroke(mm)	86*72
Displacement(L)	0.418
Power(kW)	5.7/3000	6.3/3600
Fuel consumption rate(g.kW/h)	275.1	281.5
Compression ratio	19
Lubrication system	Spring
Engine starting system	X:Recoil start E:Electric start
Diesel oil model	Summer:0#,Winter:-10#
Lube oil model	SAE10W-30(above CD grade)
Lube oil capacity(L)	1.65
Battery capacity(V-AH)	12V-36Ah
