Welding Generator Tool (KDE6700EW/6500EW)

Name: Welding Generator Tool (KDE6700EW/6500EW)
Brand: KAIAO
SKU: 104347149
Availability: InStock

Negotiable MOQ: 10 Sets (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

KAIAO

Model Number:

KDE6700EW

Wuxi Kaiao Power Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name KAIAO

Model Number KDE6700EW

Output Type AC Single Phase

Speed 3000/3600

Frequency 50/60

Rated Power 2.2

Rated Voltage 230/240

Rated Current 8.7/9.2

WUXI KAIAO POWER MACHINERY CO., LTD

GENERATOR /WELDER	Model	KDE6500EW
	Frequency:Hz	50
	Rated output:Kva	2
	Rated.AC voltage:V	230
	current:A	8.7
	No-load welding voltaged;V	65
	Rated welding voltaged:V	26--30
	Rated welding DC:A	200
	Current adjusting extension	50--200
	Electric welding load rate	50%
	Phase	Single phase
	Power factor:COS	COS=1
	Alternator type	self-excited,2-pole,single phase alternator
	Starting system:	X:Recoil Starter E/T:Electric Starter
	Operatong noise lecel(at 7m):dB(A)	X/E:77 T: 72
	Fuel tank capacity(L):L	X/E:12.5 T:15
ENGINE	Model	KA186FA
	Engine type	Single-cylinder,vertical,4-stroke air-cooled diesel engine
	Bore × Stroke:(mm)	86×72
	Fuel	Summer:0# Winter: -10#
	Lubricatiom oil Model	SAE10W-30(above CD grade)
	Lubricatiom oil volume:L	1.65
	Fuel comsumption Rate(g.kw/h)	275.1
	Displacement:L	0.418
	Power/speed:KW, r/min	5.7/3000
	Compression Ratio	19
	Combustion system	Direct lnjection
	Dimension(Lwh)	640480530
	net weight	105kg
