Arc Welding Machine (KDE300A)

Name: Arc Welding Machine (KDE300A)
Brand: KAIAO
SKU: 104347189
Availability: InStock

Negotiable MOQ: 10 Sets (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

KAIAO

Model Number:

KDE300EW

Wuxi Kaiao Power Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name KAIAO

Model Number KDE300EW

Rated Duty Cycle 50%

Dimensions 930x690x920(mm)

DUAL-USE WELDING DIESEL POWER GENERATION UNIT

Model	KDE300EW
Frequency(HZ)	50	60
Output power(kVA)	3	3.2
Voltage(V)	230	240
Current(A)	13.0	13.3
No-load welding voltage(V)	60
Rated welding voltage(V)	20-32
Rated welding DC(A)	300
Current adjusting extension(A)	50-200
Electric welding load rate	50%
Speed(r/min)	3000	3600
Phase	Single
Power factor	1
Excitation system	Self-excited constant voltage(with AVR0
Noise level(7m)dB(A)	77
Fuel tank capacity(L)	25
Structure	Open-frame
Panel	ordinary
Output socket	Two
Output terminal post	Two
Net weight(kg)	200
Dimension(LWH)	930690920
Engine model	KA840
Engine type	Single-cylinder,vertical,four-stroke air-cooled direct injection
Bore*stroke(mm)	2-86*72
Displacement(L)	0.836
Power(kW)	10.3/3000	11.3/3600
Fuel consumption rate(g.kW/h)	≤340
Compression ratio	19
Lubrication system	spring
Diesel oil model	Summer:#0 winder:-10#
Lube oil model	SAE10W-30(above CD grade)
Lube oil capacity(L)	1.65
Battery capacity(V-AH)	12v-36ah
Engine starting systme	X:recoil starter E: Electric starter
