Specifications
jaw crusher machineHigh crushing ratio
Easy maintenance
Stable performance
Even final products
Jaw crusher machine
The jaw crusher machine squeezes rock between two surfaces, one of which opens and closes like a jaw. Rock enters the jaw crusher from the top. Pieces of rock that is larger than the opening at the bottom of the jaw lodge between the two metal plates of the jaw. The opening and closing action of the movable jaw against the fixed jaw continues to reduce the size of lodged pieces of rock until the pieces are small enough to fall through the opening at the bottom of the jaw. It has a very powerful motion.
Jaw crusher machine technical parameters:
|
Model
|
Max feeding size |
Width of discharging opening |
Capability
|
Power (KW) |
speed of mainshaft (r/min) |
Weight (T) |
PEF150×250 |
125 |
10-40 |
1-3 |
7.5 |
285 |
0.7 |
PEF200×300 |
180 |
20-70 |
2-8 |
11 |
285 |
0.8 |
PEF-250×400 |
210 |
20-80 |
4-14 |
15 |
310 |
2.8 |
PEF-400×600 |
350 |
40-160 |
20-120 |
30 |
300 |
6.428 |
PEF500×750 |
425 |
50-100 |
40-110 |
55 |
275 |
11.3 |
PEF-600×900 |
480 |
72-200 |
56-192 |
75 |
255 |
17.625 |
PEF750×1060 |
630 |
80-200 |
100-250 |
90 |
250 |
29 |
PEF900×1200 |
750 |
95-200 |
120-280 |
110 |
250 |
50 |
PEF1000×1200 |
850 |
110-260 |
180-340 |
130 |
200 |
53 |
PEF1200×1500 |
1020 |
150-300 |
300-500 |
160 |
180 |
101 |
