Home > Industrial Equipment & Components > Engine & Part > Engine > KDE186FA 9HP Small Diesel Engine
KDE186FA 9HP Small Diesel Engine
Negotiable
MOQ: 10 Sets (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Fuel:
Diesel
Stroke:
4 Stroke
Cylinder:
Single Cylinder
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
KA2V840 15/16hp Air Cooling Twin Cylinder Diesel MotorUS$ 730 - 780MOQ: 5 Sets -
KA186 8Hp/6kw Single Cylinder Air-cooled 4-stroke Diesel Combustion EngineUS$ 200 - 250MOQ: 5 Sets
-
Engine 186F/8hpNegotiableMOQ: 10 Sets
-
2015 NEW DESIGN 3-10hp Diesel Engine Both Hand Start and Key Start HOT SALEUS$ 200 - 235MOQ: 10 Sets
-
8HP Diesel Engine Air Cooled KA186F Best Price and Service CE ISO BV ApprovedUS$ 200 - 235MOQ: 10 Sets
Fuel
Diesel
Stroke
4 Stroke
Cylinder
Single Cylinder
Cold Style
Other, Air-cooled
Place of Origin
Jiangsu, China
Brand Name
Kaiao
Model Number
KDE186FA
| Model | KA186FA |
| Rated output(HP/rpm) | 7.9HP/3000, 8.6HP/3600 |
| Rated output(KW/rpm) | 5.7KW/3000, 6.3KW/3600 |
| Engine type | Single-cylinder, vertical, four-stroke, air-cooled, direct injection |
| Cylinder Diameter*stroke(mm) | 86X72 |
| Piston displacement (L) | 0.418 |
| Compression ratio | 19 |
| Max. no-load speed(r/min) | 108% of Rated rotary speed |
| Min. no-load speed(r/min) | 1300 |
| Lubrication system | Pressure splash complex Type |
| Engine starting system | Recoil starter or Electric starter |
| Output terminal rotation | AnticlockWise |
| Fuel oil model | Summer:0#, Winter:-10# |
| Fuel tank capacity (L) | 5.5 |
| Fuel consumption rate(g/kW.h) | 275/3000 280/3600 |
| Oil consumption rate(g/kW.h) | 4.08 |
| Oil grade | CD grade or SAE10W-30,15W-40 |
| Valve clearance(cold state) mm | 0.10-0.15 |
| Lube oil capacity (L) | 1.65 |
| Starting motor (V,kW) | 12V 0.8kW |
| Charging generator(V,A) | 12V 3A |
| Battery capacity(V,AH) | Above 12V-36AH |
| Dimension (L*W*H)(mm) | 522*522*578 |
