Help Center186F DIESEL ENGINE
Negotiable
MOQ: 10 Sets (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Fuel:
Diesel
Stroke:
4 Stroke
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
KDE186FA 9HP Small Diesel EngineNegotiableMOQ: 10 Sets -
KA2V840 15/16hp Air Cooling Twin Cylinder Diesel MotorUS$ 730 - 780MOQ: 5 Sets
-
KA186 8Hp/6kw Single Cylinder Air-cooled 4-stroke Diesel Combustion EngineUS$ 200 - 250MOQ: 5 Sets
-
Engine 186F/8hpNegotiableMOQ: 10 Sets
-
2015 NEW DESIGN 3-10hp Diesel Engine Both Hand Start and Key Start HOT SALEUS$ 200 - 235MOQ: 10 Sets
Condition
New
Fuel
Diesel
Stroke
4 Stroke
Cylinder
Single Cylinder
Cold Style
Other, Air-cooled
Place of Origin
Jiangsu, China
Brand Name
KAIAO
Model Number
KA186F
| Model | KA186F |
| Rated output(HP/rpm) | 7.6HP/3000rpm, 8.4HP/3600rpm |
| Engine type | Single-cylinder, vertical, four-stroke, air-cooled, direct injection |
| Cylinder Diameter*stroke(mm) | 86X70 |
| Piston displacement (L) | 0.406 |
| Compression ratio | 19 |
| Rated power/Rated speed(kW/rpm) | 5.7/3000 6.3/3600 |
| Max. no-load speed(r/min) | 108% of Rated rotary speed |
| Min. no-load speed(r/min) | 1300 |
| Lubrication system | Pressure splash complex Type |
| Engine starting system | Recoil starter or Electric starter |
| Output terminal rotation | AnticlockWise |
| Fuel oil model | Summer:0#, Winter:-10# |
| Fuel tank capacity (L) | 5.5 |
| Fuel consumption rate(g/kW.h) | 275.1/3000 281.5/3600 |
| Oil consumption rate(g/kW.h) | 4.08 |
| Oil grade | CD grade or SAE10W-30,15W-40 |
| Valve clearance(cold state) mm | 0.10-0.15 |
| Lube oil capacity (L) | 1.65 |
| Starting motor (V,kW) | 12V 0.8kW |
| Charging generator(V,A) | 12V 3A |
| Battery capacity(V,AH) | Above 12V-36AH |
| Dimension (L*W*H)(mm) | 522*522*578 |
| Net weight(kg) | 47 |
