Specifications
LX200 laser marking machine1)high-precision
2)marking scope:200*200mm
3)wide application
4)handle up and down table
LX200 laser marking machine
Performance Features:
1) The machine takes YAG lamp-pumped solid laser device as the light source. By 2D fast-speed scanning lens swinging as the scheduled angles under the controlling of the computer, the laser focus on the surface of the work piece by F-θ lens to form images and realize marking and graph processing.
2) YAG lamp–pumped laser marking machine is the most widely used, the optimal cost-effectiveness and the most stable quality machine at present
3) Having large marking scope by applying the way of X-Y axis scanning.
4) Compare to galvanometer laser marking machine, PEDB-200 Laser Marking Machine could make deeper marks.
5) With moderate cost, PEDB-200 Laser Marking Machine can be applied on small-scale output work-piece.
6) It can mark date & serials number automatically.
7) Available for data communications, networking
Application Scope and material:
Automobile Parts: Pistons, piston rings, gears, shafts, bearings, clutch, lights, etc.
Electronic Components: Resistance capacitance, chips, printed circuit boards, computer keyboard, etc.
Instrument: Panel signs, name plates, precision equipment, etc.
Hardware Tools: Knives, tools etc..
Technical data:
Max Output Power: 50W
Marking Scope: 300mm×200 mm; (or customized)
Marking Depth: 0.01mm~0.3mm;
Marking Speed : ≤30mm/second;
Repeated Accuracy: 0.01mm
Laser Wavelength: 1064 um
Minimum Line Width: 0.015mm
Power Supply: 380V/50HZ
Machine Power: 2KW
