Specifications
fiber laser engraving machineMaintenance-free
Long-life
Fast processing speed
3HE -30W fiber laser engraving machine, Liser engraving machine for shell phone,metal laser engraving machine
Features and principle:
Fiber laser using an integrated overall structure,and no any pollution,and air cooled power coupling loss,with other lasers do not have the high efficiency,long life span and low maintenance properties.
Fiber laser marker laser marking applications with many unique advantages. Unlike conventional solid-state lasers use a YAG laser media, fiber laser using a long as Yb-doped double-clad fiber laser and high efficiency multimode laser diode pumping.
1.Excellent beam quality:Compared with the traditional solid laser marking machine, machine output, gathering spot diameter less than 20um. divergence angle is semiconductor-pumped laser one-fourth. especially suitable for precise, refined marking.
2.Very long working life, 100000 working hours and no need maintainance
3.Very very thinner lines than traditional solid laser marking systerms.
4.Wide application, could work on NON-METAL and METAL material.
5.High converstion efficiency of electro-optic, the power consumption of the whole equipment is below 600W, it is only 1/10 of the solid laser marking machine pumped by the lamp.
The scope of using:
Electronic components, electrical appliances, telecommunications, auto parts, precision hardware, gifts and jewelry, medical equipment, instruments, eyeglasses and clocks and sanitary ware industry, not suitable for highly reflective material.
Technical parameters:
Average output power |
5W,10W,20W(continuous or pulse) |
Laser wavelength |
1064nm |
Power adjustment range |
10-100% |
Repetition rate |
20-80KHz |
Laser beam quality m2 |
1.4-1.8 |
Divergence angle |
0.3mrad |
Mark |
Static or mobile marking |
Marking LineWidth |
0.01-0.2mm |
Minimum focusing spot |
0.01mm |
Minimum character height |
0.2mm |
Re-precision |
0.2um |
Marking speed |
≤7000mm/s |
Supported formats |
Graphics, text, bar codes, two-dimensional codes, automatic marking the date, frequency, lot number, serial number, file links |
Mark character types |
Vector and bitmap graphics, text |
Operating system |
Windows XP, supporting PLT, PCX, DXF, BMP etc file format |
Marking range |
50x50/100 x100/150 x150mm |
Dimensions(L*M*Hmm) |
550 x900 x1200 |
Electrical requirement |
100-240V, Single phase,500W |
Key models:3HE-FM5,3HE-FM10,3HE-FM20
Dongguan sanhe laser technology limited company is a company engaged in the development, production and sales of well-paid technology enterprise, is located in Dongcheng, Dongguan city industrial zone, with a modern production plant, the strength, talent is sufficient, have a professional research and development and production team.Company since its inception, the introduction of advanced laser technology and convergence with international laser industry solutions, and well-known institutions and optoelectronic Research Institute maintains a long-term good relations of cooperation, in the field of energy development and application of new laser bold in innovation, the pursuit of excellence.
Sanhe laser company have launched a series of large power laser cutting series, the laser marker series, industrial laser equipment, such as laser welding, the company relies on excellent quality and leading-edge technology, to meet the requirements of different lasers use area.Equipments are exported to the United States, Korea, India, Viet Nam, Japan, Malaysia and many other countries.
I. The whole set of machine is guaranteed for one year, not including normal replacement of wearing parts.
II. We depend on our domestic reputation and customer satisfaction to succeed. Therefore, your feedback is extremely important to us.
III. If you have any particular suggestions or questions on our products, please feel free to contact us. We will be very grateful and reply your email or fax within 24 hours.
Please let us kown:
1.what kind of machine you need
2.the information about the material you want to prcess
3.what is your business scope?Are you end user or distributor?
We will be very happy to help you in any way we can.
