7GX-9.0Q4-stroke MIHENG 12HP Gasoline Outboard Motor(4HP-20HP)

7GX-9.0Q4-stroke MIHENG 12HP Gasoline Outboard Motor(4HP-20HP) thumbnail-1
7GX-9.0Q4-stroke MIHENG 12HP Gasoline Outboard Motor(4HP-20HP) photo-1
Negotiable MOQ: 1 Carton (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Engine:
4 Stroke
Fuel Type:
Gasoline
Contact Supplier Request Quote Chat Now
Chongqing Miheng Power Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
CHONGQING
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Engine 4 Stroke
Fuel Type Gasoline
Cylinders 1
Engine Position Outboard

Specifications

12hp, 4stroke,9kw,electric start/hand start,shaft connection,,direct injection ,energy efficient

Direct Injection, Energy Efficient

Owner of 7 national-level IPR .

 duct:

 7GX-9.0Q4-stroke MIHENG 12HP Gasoline outboard motor(4HP-20HP)

 2.DEMO FIGURE

7GX-9.0Q4-stroke MIHENG 12HP Gasoline outboard motor(4HP-20HP)

 3.Technical Specifications

MODELS 7GX-9Q Gasoline outboard engine
ENGINE TYPE SINGLE CYLINDER, HORIZONTAL TYPE, FOUR STROKE, AIR COOLED, OHV
Bore x Stroke (mm x mm) 90×66mm×mm
Displacement (L) 0.420L
Rated Speed of Output Shaft 1560r/min
Max.torque(N•m/rpm) 26.5N.m/2500r/min
Fuel Consumption(g/kW•h) ≤395
Power Rated Output KW/Ps 9.0KW (12P)
Direction of Output Rotation Anticlockwise (from the output side)
Valve Clearance (mm) Intake valve :0.1-0.15mm Exhaust valve: 0.15-0.20mm
Starting Way Recoil Start/Electric Start
Fuel Fuel Capacity(L) 6 L
Mark 93#
Engine Lubrication Method of Lubrication Pressure Splash Compound
Lubrication Oil SAE10W-30, Level CC above
Lubrication Oil Capacity(L) 1.1L
Engine Size (LxWxH) (mm) 405×450×443
Engine Net Weight (Kg) ≤32Kg
Machinery Net Weight (Kg) ≤68Kg
Speed of Impeller 1560r/min
Diameter of Impeller 340mm
Transmission Fluid Middle Duty Industrial Gear Oil HL-20
Transmission Capacity 3L
Applicable Scope 6-10Meters Ship,Maximum load 2tons

 4.Functions added



5.Product details



6.Modern workshop and new office.

7.Certificated



8.MIHENG outboard engine

9.Comparison between old and new type of outboard engines





10. Delivery

11.Made in china.
