7GX-14.7Q 20hp 4strokes MIHENG Gasoline Outboard Engine
Specifications
20hp 4stroke,electric start,shaft connection,gear oil for transmission lubrication,direct injection energy efficientDirect Injection, Energy Efficient
Owner of 7 national-level IPR .
duct:
2.DEMO FIGURE
3.Technical Specifications
MODELS |
7GX-14.7Q gasoline outboard engine |
|
ENGINE TYPE |
V-DOUBLE CYLINDERS |
|
Bore x Stroke (mm x mm) |
78×71 mm×mm |
|
Displacement (L) |
0.678L |
|
Rated Speed of Output Shaft |
1560r/min |
|
Max.torque(N·m/rpm) |
43.5N.m/2500r/min |
|
Fuel Consumption(g/kW·h) |
≤360 |
|
Power |
Rated Output KW/Ps |
14.7KW(20P) |
Direction of Output Rotation |
Anticlockwise (from the output side) |
|
Valve Clearance (mm) |
Intake valve :0.1-0.15mm Exhaust valve: 0.15-0.20mm |
|
Starting Way |
Recoil Start/Electric Start |
|
Fuel |
Fuel Capacity(L) |
—— |
Mark |
≥90# |
|
Engine Lubrication |
Method of Lubrication |
Pressure Splash Compound |
Lubrication Oil |
SAE10W-30, Level CC above |
|
Lubrication Oil Capacity(L) |
1.5L |
|
Engine Size (LxWxH) (mm) |
455×400×450 |
|
Engine Net Weight (Kg) |
≤45Kg |
|
Machinery Net Weight (Kg) |
≤81Kg |
|
Speed of Impeller |
1560r/min |
|
Diameter of Impeller |
380mm |
|
Transmission Fluid |
Middle Duty Industrial Gear Oil HL-20 |
|
Transmission Capacity |
3L |
|
Applicable Scope |
8-14 Meters Ship |
|
4.Functions added
5.Product details
6.Modern workshop and new office.
7.Certificated

9.Comparison between old and new type of outboard engines
10. Delivery
11.Made in china.
