7GX-14.7Q-QL 20hp 4strokes MIHENG Gasoline Outboard Engine

7GX-14.7Q-QL 20hp 4strokes MIHENG Gasoline Outboard Engine thumbnail-1
7GX-14.7Q-QL 20hp 4strokes MIHENG Gasoline Outboard Engine photo-1
Negotiable MOQ: 1 Carton (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Engine:
4 Stroke
Fuel Type:
Gasoline
Contact Supplier Request Quote Chat Now
Chongqing Miheng Power Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
CHONGQING
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Engine 4 Stroke
Fuel Type Gasoline
Cylinders 2
Engine Position Outboard

Specifications

20hp 4stroke,electric start,shaft connection,gear oil for transmission lubrication,direct injection energy efficient

Direct Injection, Energy Efficient

Owner of 7 national-level IPR .

 duct:

 7GX-14.7Q-QL 20hp 4strokes MIHENG gasoline outboard engine

 2.DEMO FIGURE

7GX-14.7Q-QL 20hp 4strokes MIHENG gasoline outboard engine

 3.Technical Specifications

 MODELS

7GX-14.7Q-QL gasoline outboard engine

ENGINE TYPE

V-DOUBLE CYLINDERS

Bore x Stroke (mm x mm)

78×71 mm×mm

Displacement (L)

0.678L

Rated Speed of Output Shaft

1560r/min

Max.torque(N·m/rpm)

43.5N.m/2500r/min

Fuel Consumption(g/kW·h)

≤360

Power

Rated Output  KW/Ps

14.7KW(20P)

Direction of Output Rotation

Anticlockwise (from the output side)

Valve Clearance (mm)

Intake valve :0.1-0.15mm  Exhaust valve: 0.15-0.20mm

Starting Way

Recoil Start/Electric Start

Fuel

Fuel Capacity(L)

——

Mark

≥90#

Engine Lubrication

Method of Lubrication

Pressure Splash Compound

Lubrication Oil

SAE10W-30, Level CC above

Lubrication Oil Capacity(L)

1.5L

Engine Size (LxWxH) (mm)

455×400×450

Engine Net Weight (Kg)

≤45Kg

Machinery Net Weight (Kg)

≤81Kg

Speed of Impeller

1560r/min

Diameter of Impeller

380mm

Transmission Fluid

 Middle Duty Industrial Gear Oil HL-20

Transmission Capacity

3L

Applicable Scope

8-14 Meters Ship





















































 4.Functions added

5.Product details

 6.Modern workshop and new office

7.Certificated



8.MIHENG outboard engine

9.Comparison between old and new type of outboard engines





10. Delivery

11.Made in china.
