7GX-5.3Q 7hp 4strokes MIHENG Gasoline Outboard Engine

7GX-5.3Q 7hp 4strokes MIHENG Gasoline Outboard Engine thumbnail-1
7GX-5.3Q 7hp 4strokes MIHENG Gasoline Outboard Engine photo-1
Negotiable MOQ: 1 Carton (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Engine:
4 Stroke
Fuel Type:
Gasoline
Contact Supplier Request Quote Chat Now
Chongqing Miheng Power Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
CHONGQING
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Engine 4 Stroke
Fuel Type Gasoline
Cylinders 1
Engine Position Outboard

Specifications

7hp 4stroke,electric start,shaft connection,gear oil for transmission lubrication,direct injection energy efficient

Direct Injection, Energy Efficient

Owner of 7 national-level IPR .

 duct:

 7GX-5.3Q 7hp 4strokes MIHENG gasoline outboard engine

 2.DEMO FIGURE

7GX-5.3Q 7hp 4strokes MIHENG gasoline outboard engine

 3.Technical Specifications

MODELS 7GX-5.3 Gasoline outboard engine
ENGINE TYPE SINGLE CYLINDER, HORIZONTAL TYPE, FOUR STROKE, AIR COOLED, OHV
Bore x Stroke (mm x mm) 75×60mm×mm
Displacement (L) 0.265L
Rated Speed of Output Shaft 1560r/min
Max.torque(N•m/rpm) 15.5N.m/2500r/min
Fuel Consumption(g/kW•h) ≤395
Power            Rated Output KW/Ps 5.3KW (7.2P)
Direction of Output Rotation Anticlockwise (from the output side)
Valve Clearance (mm) Intake valve :0.1-0.15mm Exhaust valve: 0.15-0.20mm
Starting Way Recoil Start/Electric Start
Fuel Fuel Capacity(L) 4.6 L
Mark 93#
Engine Lubrication Method of Lubrication Pressure Splash Compound
Lubrication Oil SAE10W-30, Level CC above
Lubrication Oil Capacity(L) 0.95L
Engine Size (LxWxH) (mm) 380×430×415
Engine Net Weight (Kg) ≤25Kg
Machinery Net Weight (Kg) ≤61Kg
Speed of Impeller 1560r/min
Diameter of Impeller 360mm
Transmission Fluid Middle Duty Industrial Gear Oil HL-20
Transmission Capacity 3L
Applicable Scope 5-7 Meters Ship,Maximum load 2 tons

4.Functions added



5.Product details



6.Modern workshop and new office.

7.Certificated



8.MIHENG outboard engine

9.Comparison between old and new type of outboard engines





10. Delivery

11.Made in china.
