Specifications
1.TAIYITO Two-way/gang X10 touch light switch2.CE
3.Crystal glass panel
4.LED backlight
5.Accept OEM
TAIYITO Two-way/gang X10 touch light switch
Model |
Name |
Description |
TDXE4203S |
Touch Screen Fluorescent Lamp Switch(Load Max1500W) |
It is suited to big power lights,for example a big ceiling lamp from upstairs to downstairs |
TDAE4401S |
Touch Screen Incandescence Lamp Micro Dimmer Switch |
It is suited to Incandescence Lamp,it can dimmer the light. |
TDXE4403S |
Touch Screen Fluorescent Lamp/Appliance Switch |
It is suited to Fluorescent Lamp,and small power appliance. |
TDXE4404S |
Touch Screen 2-way Fluorescent Lamp/Appliance Switch |
It is a two-way control Switch. |
TDXE4466S |
Touch Screen Automatic Shutter Switch |
It is a switch control electric shutter. |
TDXE4602S |
Touch Screen 2-way Scene Switch(Max 16 addresses per scene) |
It is a scene control switch,could control Max 16 addresses lights or appliance per scene |
Features:
l Replace conventional switches , replacing mechanical buttons with touch screen , longer life.
l LED backlight touch buttons for switch control,address code of lights is clear to see.
l Assorted many colors available so that to personalized the product.Gorgeously appearance is right down your decoration.
l The words displayed on the panel could be change according to customer’s require.
l Bidirectional communication by power line in high speed with the feedback function
l Can be installed in any 86 -style junction box , socket panel ; ultra-thin design .Dimensions : 86X86X39mm
l Simple setup, six seconds to complete the study; equipped with powerful noise suppression circuit.
l Touch switch control Fluorescent Lamp respond all ON & all OFF;touch switch control appliance only respond all OFF.
Technical Specifications:
l Rated voltage 220VAC ± 10%, 50Hz ;equipment load ≤ 1000W
l static power ≤0.5W ;ambient temperature: -10~50°C
l Two-way communication up time ≤ 2s
Installation:
For the lamp which you want to control, only need to put the touch screen Fluorescent Lamp/Appliance Switch inside the standard 86 type switch box, the switch box should have the naught wire, if you don’t have the naught wire just put it on the lamp. You do not need any other switch panel any more.
