Remote Control Motorized Curtain Motor, Automatic Curtain, Electric Curtain System

Remote Control Motorized Curtain Motor, Automatic Curtain, Electric Curtain System thumbnail-1
Remote Control Motorized Curtain Motor, Automatic Curtain, Electric Curtain System photo-1
US$ 50 - 100 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
TYT
Model Number:
TDZ4468S
Use:
Universal
Contact Supplier Request Quote Chat Now
Tianjin Taiyito Technology Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin for electric curtain
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name TYT
Model Number TDZ4468S
Use Universal
Place of Origin Tianjin, China

Specifications

motorized curtain motor, automatic curtain, electric curtain system
1.electric curtain system
2.factory R&D
3.CE

  Remote control motorized curtain motor, automatic curtain, electric curtain system

Product Description

Specification: motorized curtain motor,automatic curtain, electric curtain system

Voltage

AC220V-240V,50Hz

Power

45W

Torque

1.2N.m

Speed

88.6r/min

Insulation Class

E

Protection Class

IP41

Work method

S3



Accessories: Remote control motorized curtain,  automatic curtain, electric electric curtain



Type (horizontal open)

Model No.

Description




Electric -Driven only, Cannot control by hand when power off

TDX4466(45W)

Flat-open Electric Curtain Motor(45W)



TDX4466G

Flat-open Electric Curtain Track



TDX4465

Curtain Indepdence 3-way mini remote controller



TDX4464

Curtain Independence Switch Controller



Total 1 set



Electric -Driven or Manual-driven when power off

TDX4467(60W)

Flat-open Electric&manual Curtain Motor(60W)



TDX4467G

Flat-open Electric&manual Curtain Track (60W)



TDX4465

Curtain Indepdence 3-way mini remote controller



TDX4464

Curtain Independence Switch Controller



Total 1 set



NEW Arrival ! (such 3 pc work together)

TDX4470

Power assistant Flat-open Electric&manual Curtain Motor



TDX4467G

Power assistant Flat-open Electric&manual Curtain Track (60W)



TDX4463

Curtain Indepdence mini remote controller( for TDX4470)



Total 1 set







Type (roller blinds)

Model No.

Description




Electric -Driven only, Cannot control by hand when power off

TDX4468

Roller blind electric curtain Motor(10N)



TDX4468G

Roller blind Electric Curtain Track(φ50)



TDX4465

Curtain Indepdence 3-way mini remote controller



TDX4464

Curtain Independence Switch Controller



Total 1 set





Taiyito Remote control motorized curtain, electric curtain,automatic curtain



Curtain type:

Remote control motorized curtain motor, automatic curtain, electric curtain system





Main used and control function

It used in bidirectional zigbee system,it can receive the wireless 2.4G control signal and transmit related signal.It is send local control signals of ON and OFF.It is controlled product, connect with electrical Motor together to control electrical curtain motor positive rotation and reverse then to realize curtain turn on and off. It can connect to two electric curtain motor.







The function:

1.You can use the remote controller to turn on/off the electrical curtain which you put this kind of touch screen switch in any direction at home, also can check the working status.
2.When you are on the way home, you can make a call firstly to turn off the Curtain.
3.When you are in another province for business, you also can turn on/off your curtain by web controller-a very popular and modern way to control in home curtain.
4.This touch screen switch can also be controlled by Scene controller, for example, only pressing one key you can turn on the TV, water heater, and close the curtain.
5.Also can accept the timing control, “on” and “off” control
6."on” and “off” words on touching panel is transformed, it shows the curtain working status conveniently

Feature:



1.Metal drawbench, Fashionable Texture, various color, individual design, and you can change the icon at random.
2.The design of colorful background prompt lights produce more sense of the fashion from science and technology.
3.Ultra-high power curtain motor , its maximum reach 300w. As long as you install the curtain switch, the electric curtain can accept variety of intelligent controlling from the Zigbee system.
4.Easy installation , there is only need reserve one null wire in the standard 86type junction box
5.Higher speed communication, more powerful network, two-way communication.
6. Wide voltage power supply mode, which can meet all of customer demand from the different country, different area.
7.We provide different compatible interfaces as well, such as dry contact, RS458. So that our ZigBEE system is able to integrate with other systems. And it can do network quickly and realize lights, appliances intelligent controlling



Certificate of automatic curtain

 Remote control motorized curtain motor, automatic curtain, electric curtain system
