Specifications
laser wire stripping machine1.integrated the funtion of automatic control
2.operation speed and cutting precision is high
laser wire stripper machine
LB-RFB20 laser stripper machine is our own developed for the professional metal shielded product.
It provides good solution for the under AWG52# the very thin beam of metal shield layer.
This machine has high-performance and can be continuous work for 24 hour at full load.
Technical Advantage
l Adopts the integration of whole structure, beautiful shape, humanized operation process.
2 Using fiber laser, enhance stability and laser equipment life, life can reach 100000 hours.
3 Adopted high-speed motor, processing efficiency is high, is the same laser wire stripping machine a few times.
Electro-optic conversion efficiency is high, the whole machine is less than 800 w power consumption, low carbon environmental protection.
mini filament metal shielding layer off below AWG#52
1.Can the very good stripping coaxial metal shielding layers, not cause shield deformation and damage insulating layer, conductor,the rate of finished products can reach 100%.
2.The operation is simple, to the traditional process is difficult to complete a variety of special requirements of wire stripping can be easily accomplished.
3.Non mechanical processing, do not produce any mechanical extrusion or stress to materials, good at processing quality.
4.Precision control of strip location, size and depth, reposition and consistency of cable is good.
5.Cooperate with CO2 series laser strip machine can achieve mini filament coaxial with automatic processing line.
Field: Applicable to LCD displays, mobile phone, notebook computers, video cameras, digital cameras, electronic dictionary, medical equipment and other industries internal data lines,
signal lines, coaxial cable shielding layer stripping, particularly applicable to line below AWG# 52
Technical Parameter
Laser Power |
20W |
|
Laser wavelength |
1064nm |
|
Work schedule |
100mm |
|
Cutting speed |
0~30000mm/min |
|
Positioning precision |
±0.02mm |
|
Cooling system |
air-cooled |
|
Power supply |
AC220V/50HZ |
|
power consumption |
≤0.8KW |
|
Dimension |
670×790×1250mm |
workshop
