UV spot varnish Curing machine
Specification of UV spot varnish Curing machine:
1. This machine belong to Transmission UV Curing Equipment; It is used for the curing of Ink, Coating, Resin; It has these characters of small volume, light weight and perfect design; it can move conveniently and place on the desk;
2. The Reflector of this equipment adopt focusing type baffle-board;
3. It's very convenient to adjust the height of UV lamp; it has an uniform luminance and long lifetime;
Application of UV spot varnish Curing machine:
This is one kind of UV Curing Equipment. It is widely used in the UV paint surface coating of mobile phone shell, membrane switch, electronic products plastic shell. It is also used in Curing electronic components, liquid crystal slice,terminal gum, mobile phone assembly gum, plastic assembly gum and LCD; It has a small volume and light weight, craft and move conveniently.
Sample Show of UV spot varnish Curing machine:
Technical Parameters of UV spot varnish Curing machine:
Using Area: 750*2800
The width of Teflon: 750mm
Overall Size (L*W*H): 2800*1200*1500mm
The Drying Speed:5-22m/min
Wavelength: 365nm
Power:380V
Wattage:18KW
The material of mesh belt: Teflon
Production Department:
Exhibition Show:
OEM and ODM: our factory can custom according to your requirement with our excellent engineers who have more than 10 years experience.
