UV Laminating Machine

UV Laminating Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Guangdong, China
Brand Name:
ebola
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Guangdong, China
Brand Name ebola
Model Number YBL-UV300-1
Automatic Grade Semi-Automatic

Specifications

UV Laminating machine
1.Factory Price
2.The length of feeding material: 250 mm
3.Wavelength: 365nm

UV Laminating machine



Specification:

1.  This machine belong to Transmission UV Curing Equipment; It is used for the curing of Ink, Coating, Resin; It has these characters of small volume, light weight and perfect design; it can move conveniently and place on the desk;

2.  The Reflector of this equipment adopt focusing type baffle-board;

3.  It's very convenient to adjust the height of UV lamp; it has an uniform luminance and long lifetime;

Application:

This is one kind of UV Curing Equipment. It is widely used in the UV paint surface coating of mobile phone shell, membrane switch, and plastic shell of electronic products. It is also used in Curing electronic components, liquid crystal slice, terminal gum, mobile phone assembly gum, plastic assembly gum and LCD; it has a small volume and light weight, craft and move conveniently.

Technical Parameters:

(1)Overall Size (L*W*H): 1020*660*557mm

(2)The length of feeding material: 250 mm

(3)The length of discharging material: 270mm

(4)The width of Teflon: 300mm

(5)The material of mesh belt: Teflon

(6)The height of feeding material: 80±10mm

(7)The height of feeding material hole: 10~120mm

(8)Wattage of Tube: 2KW/piece, the shinning height of lamp tube can be adjusted by manual

(9)The shinning width of light tube: 300mm

(10)The shinning width of light tube: 300mm

(11)Exhaust Fan: 38W,2set

(12)Wavelength:   365nm

(13)Stable Time:     about 3 minutes

(14)Lifetime:  1000hours, (we can promise 800 hours)

(15)Transmission Motor: 25W/set

(16)Transmission Speed: 0-12m/min, the transmission speed can be adjusted stepless;

(17)The transmission way: chain

(18)The way of Regulating Speed: electronic speed regulation

(19)Power: 220V

(20)Net Weight: 65kg

(21)Gross Weight: 70kg;

OEM: our factory can custom according to your requirement with our excellent engineers who have more than 10 years experience
