Help CenterNMRV Mechanical Worm Reducer
Related Products
-
Motoreductores Combination With Output Flange Hollow Shaft Motovrio-Like Worm Speed ReducerUS$ 22 - 300MOQ: 1 Piece -
Stable Worm Gearbox for Textile IndustriesUS$ 24.5 - 335MOQ: 1 Piece
-
Shaft Mounted Motovario Like Aluminium Alloy Worm Speed ReducerUS$ 22 - 300MOQ: 1 Piece
-
NMRV040 Quality Gearbox Gearbox Motor, Right Angle GearboxUS$ 30 - 87MOQ: 1 Piece
-
NMRV040 Wrom Gear Box Speed Reducer MachineUS$ 21.2 - 22.2MOQ: 1 Set
Our facotyr has been in the manufacture & export of RV series mechanical worm reducers for years.Our quality control strictly complies with the ISO9001:2008 system,able to provide to all customers mature products in competitive prices.
Features
- Wide transmission rate, strong output torque
- Structure: base-mounted, input shaft, input flange, additional single or double output shafts
- Compact mechanical structure, light weight, small volume
- Good temperature change resistance
- Smooth operation with lower noise or vibration
- Easy mounting, free linking, high efficiency
- Wide range of application
Technical data:
| Model | RV025 030 040 050 063 075 090 110 130 150 |
| Single unit versions |
NMRV - fitted for motor flanged coupling, NRV - with input shaft, NMRV-E motor flanged coupling with worm extension shaft, NRV-E with double extension worm shaft, |
| Power | 0.06----15KW |
| Single unit reduction ratio | 1:5 7.5 10 15 20 25 30 40 50 60 80 100 |
| Output torque | 2.6---1195N.M |
| Worm shaft | 20CrMnTi with carburizing and quenching.The hardness of surface is 56-62HRC with carbonized layer 0.5-0.8mm |
| Worm wheel | worm mandrel is HT250,and worm ring gear,ZQSn10-1 |
Available versions for single unit
Payment of samples: samples are charged,but it will be refundable by means of deduction from the payment of the orders gradually later;
Package for delivery: one pc in carton box,then several cartons / wooden pallet; or follow the instruction of the buyer's package requirements;
We support the ways of delivery by sea,by air and by land for the bulk orders;
For samples,the delivery can be DHL,TNT,Fedex,EMS or the special itinerary to the buyer's location;
Warranty & after-sale service: one year from the date in the B/L,on proper operation conditions.Free technical support all along.
For more details,please contact me by email or by cell phone as the fllowing business card.I am always ready to serve you well,fast and prompt response,
