Home > Products > Wall Mounted Indoor LED Screen Full Color > hot hot !! New products outdoor led display for advertising
hot hot !! New products outdoor led display for advertising
- 1000 Square Meter / Square Meters per Month
- SHENZHEN
- T/T
Product Details
Place of Origin: | Guangdong, China | Brand Name: | SunYEX | Model Number: | SY-IF5 |
Usage: | Indoor | Tube Chip Color: | Full Color | Display Function: | Video |
Pixels: | Other, 5mm | Screen Dimension: | Customizing Available |
Packaging Details
Wooden Box
Product Description
hot hot !! New products outdoor led display for advertising
No. | Type | Full Color |
1 | Pixel Configuration | 1R+1G+1B |
2 | LED Type | SMD3528 |
3 | Module Resolution | 32pixels(H)×32pixels(W) |
4 | Module Dimension | 160(H)×160mm(W)×160mm(L) |
5 | Power Consumption(average) | 550w/ m2 |
6 | Power Consumption(max) | 900 w/ m2 |
7 | Density | 40000pixels/m2 |
8 | Brightness | >2500 nits |
9 | Color | 16.7 M |
10 | Brightness Control | Manual/Auto |
11 | Gray Scale Rectification | rrectification |
12 | Picture Regulation | Contrast/Chroma regulation/Module brightness regulation |
13 | Drive Mode | 1/8 duty |
14 | Refresh Rate | 960HZ |
15 | Control Mode | Synchronization control |
16 | Video Interface | S-Video, VGA, DVI etc. |
17 | Life Time | 100,000 hours |
18 | Mean Time To Failure | >10,000 hours |
19 | Blind LED | None |
20 | Working Temperature | -35°C~+55°C |
21 | Relative Humidity | 10%-95%RH |
22 | Display Flatness | The display:±1mm Gap between modules:1mm |
23 | Display Information | Text, Video and Picture etc. |
24 | Voltage | 220V±10%,380V±10% |
25 | Communication Distance | <20km |
Front View of Module
Front View of Cabinet
Back View of Cabinet
Inside View of Cabinet
Project View
Project View
Aging Test in SunYEX Factory
Strict Incoming Quality Check and Selection for Raw Material & Technology Advantages
Our advantage below:
1. LED: Antistatic>5000V
2. High temperature resistant>300°C
3. 14mil LED chips
4. 1.2mil gold wire
5. Copper brackets specially for LED display requiring cooling rapidly, excellent soldering performance.
6. Top quality of epoxy resin glue by Taiwan’s top company. Anti-ultraviolet ray, expansion & shrinkage resisting
7. Adopting Japanese Nichia LED classification standard to ensure the uniformity of LED color & brightness.
8. Connectors: above 2 mil brass connectors, phosphor copper,100% salt spray PH experiment, difficult to be oxidated and corroded.
9. Extreme flexibility,
10. Pluggable times is above 200 times.
11. High endurance in normal climate with long life span>10 years.
12. Shell: Using PC of German Bell Co. High intensity, long life span, anti-ultraviolet, able to withstand outdoor rigorous ambient, high and low temperature resistance, fire with the UL standard grades.
Mask: using special anti-ultraviolet non-shine process, good uniformity.
PCB: using PCB with UL certification, thickness of copper>one ounce, greatly extending the useful life and enhancing corrosion resistance and reliability.
Power: all using Taiwan power with UL and CE certification, enhancing the reliability of the screen power supply.
Production Advantages
Equipment
1. SunYEX has several auto production lines equipment with Taiwan auto-encapsulate machine, Taiwan Chang-Yu handler, and the production of LED meets the demand of high quality standard LED display.
2. Using full set of injection machine to meet the high quality requirements for shells, masks.
3. LED lead-free reflection wave soldering machine.
Features:
1. High uniformity for LED
2. High performance of anti-vibration
3. Easy assembly
4. Extreme low blind LED rate.
5. CE UL FCC certified
Company Profile
SunYEX Optoelectronic Co., Ltd. is a comprehensive enterprise specializing in designing, researching, developing and manufacturing LED indoor/outdoor LED displays and other LED products with advanced technologies and software. Relying on abundant capital and technology, we are rated as "Show Business Credit Unit Model". We are also the member of Chinese Optical Photoelectric Association. We have passed ISO9001:2000 quality inspection. We have established far-ranging international strategy relationships with our partners, and share the benefit from the international cooperation. We are very proud of our high quality products that meet world's industrial standards such as CE, UL, RoHS, etc.
