Indoor p3 led display modules with great performance

Name: Indoor p3 led display modules with great performance
Brand: SunYEX
Price: USD $1 - 1,000 / Square Meter

FOB Price

USD $1 - $1,000 / Square Meter

1 Square Meter(Min.Order)

Supply Ability 1000 Square Meter / Square Meters per Month
Port SHENZHEN
Payment Terms:T/T

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:	Guangdong, China	Brand Name:	SunYEX	Model Number:	SY-IF6
Usage:	Indoor	Tube Chip Color:	Full Color	Display Function:	Video
Pixels:	Other, 6mm	Screen Dimension:	Customizing Available

Packaging Details

Wooden Box

Product Description

Indoor p3 led display modules with great performance

No.	Type	Full Color
1	Pixel Configuration	1R+1G+1B
2	LED Type	SMD3528
3	Module Resolution	16pixels(H)×32pixels(W)
4	Module Dimension	96mm(H)×192mm(W)×160mm(L)
5	Power Consumption(average)	450w/ m2
6	Power Consumption(max)	900 w/ m2
7	Density	27777pixels/m2
8	Brightness	>1500 nits
9	Color	16.7 M
10	Brightness Control	Manual/Auto
11	Gray Scale Rectification	rrectification
12	Picture Regulation	Contrast/Chroma regulation/Module brightness regulation
13	Drive Mode	1/8 duty
14	Refresh Rate	960HZ
15	Control Mode	Synchronization control
16	Video Interface	S-Video, VGA, DVI etc.
17	Life Time	100,000 hours
18	Mean Time To Failure	>10,000 hours
19	Blind LED	None
20	Working Temperature	-35°C~+55°C
21	Relative Humidity	10%-95%RH
22	Display Flatness	The display:±1mm Gap between modules:1mm
23	Display Information	Text, Video and Picture etc.
24	Voltage	220V±10%,380V±10%
25	Communication Distance	<20km

Front View of Module

Front View of Cabinet

Back View of Cabinet

Inside View of Cabinet

Project View

Aging Test in SunYEX Factory

Strict Incoming Quality Check and Selection for Raw Material & Technology Advantages

Our advantage below:

1. LED: Antistatic>5000V

2. High temperature resistant>300°C

3. 14mil LED chips

4. 1.2mil gold wire
5. Copper brackets specially for LED display requiring cooling rapidly, excellent soldering performance.

6. Top quality of epoxy resin glue by Taiwan’s top company. Anti-ultraviolet ray, expansion & shrinkage resisting

7. Adopting Japanese Nichia LED classification standard to ensure the uniformity of LED color & brightness.
8. Connectors: above 2 mil brass connectors, phosphor copper,100% salt spray PH experiment, difficult to be oxidated and corroded.

9. Extreme flexibility,

10. Pluggable times is above 200 times.

11. High endurance in normal climate with long life span>10 years.
12. Shell: Using PC of German Bell Co. High intensity, long life span, anti-ultraviolet, able to withstand outdoor rigorous ambient, high and low temperature resistance, fire with the UL standard grades.
     Mask: using special anti-ultraviolet non-shine process, good uniformity.
     PCB: using PCB with UL certification, thickness of copper>one ounce, greatly extending the useful life and enhancing corrosion resistance and reliability.
    Power: all using Taiwan power with UL and CE certification, enhancing the reliability of the screen power supply.

Production Advantages

Equipment

1. SunYEX has several auto production lines equipment with Taiwan auto-encapsulate machine, Taiwan Chang-Yu handler, and the production of LED meets the demand of high quality standard LED display.
2. Using full set of injection machine to meet the high quality requirements for shells, masks.

3. LED lead-free reflection wave soldering machine.

Features:

1. High uniformity for LED
2. High performance of anti-vibration
3. Easy assembly
4. Extreme low blind LED rate.
5. CE UL FCC certified

Company Profile

Zhongshan Sunyex Optoelectronic Co., Ltd.

SunYEX Optoelectronic Co., Ltd. is a comprehensive enterprise specializing in designing, researching, developing and manufacturing LED indoor/outdoor LED displays and other LED products with advanced technologies and software. Relying on abundant capital and technology, we are rated as "Show Business Credit Unit Model". We are also the member of Chinese Optical Photoelectric Association. We have passed ISO9001:2000 quality inspection. We have established far-ranging international strategy relationships with our partners, and share the benefit from the international cooperation. We are very proud of our high quality products that meet world's industrial standards such as CE, UL, RoHS, etc.

Contact Us

Zhongshan Sunyex Optoelectronic Co., Ltd.: Contact nameLeila H.; Phone86-760-85928337; AddressNo. A309, (Jintao Business Tower) No. 2, Xianshi 1st Rd., South Zone
