1.The description of RO-5000 Mixed Bed Ion Exchanger Water Treatment System
According to exchanging filler, Ion Exchanger divides into three types :Cation and Anion beds ,Mixed bed and Regenerated bed. Cation and Anion beds run by countercurrent regeneration; According to regeneration style , Mixed bed classifies into three types: column inside regeneration,anion resin transferring outside regeneration and Cation and Anion resin all transferring outside regeneration.Regeneration process and regeneration device are used to regenerate resin transferred out of mixed
2.Flow chart of RO-5000 Mixed Bed Ion Exchanger Water Treatment System
Nos. |
Items |
Information |
1. Pre-treatment part | ||
1.1 |
Source water tank |
Store source water and let water have a sedimentation before entering plant. |
1.2 |
Booster pump |
Provide power for pretreatment & RO system. |
1.3 |
Sand filter |
Different size of quartz sand will be put in the sand filter. Remove turbidity, SS matter, organic matter, colloid, etc. |
1.4 |
Active carbon filter |
Remove color, free chloride, organic matter, harmful matter, etc. Protect and prolong the life of RO membrane. |
1.5 |
Water softener |
Reduce water hardness. |
1.6 |
Control heads |
RX-Series, full auto control. |
1.7 |
Pipeline&fittings |
UPVC. |
2. RO main body part | ||
2.1 |
PP filter |
Prevent large particles, iron, dust, SS matter, impurity into RO membrane. Protect and prolong working life of RO system. |
2.2 |
High pressure pump |
Provide power for RO system. Provide power for RO system, equipped with over-heat protect, pressure controller. |
2.3 |
RO system |
Removes: lead, cooper, barium, chromium, mercury, sodium, cadmium, fluoride, nitrite, nitrate, and selenium. |
2.4 |
Skid |
SUS. |
3. Ion exchange system | ||
3.1 |
PP filter |
Remove tiny impurities in water. |
3.2 |
Booster pump |
Provide power for ion exchange. |
3.3 |
Ion exchange resin |
Further remove ions in water. Purolite from UK. |
3.4 |
Skid |
SUS |
4. Control system | ||
4.1 |
Control panel |
SUS/A3 carbon painted. |
4.2 |
PLC mode |
Mistubishi/Siemens. Working process writen indise. |
4.3 |
Touch screen |
WeiNview/Siemens. Full auto control, easy to operate. |
4.4 |
Components |
Omron/Schneider. High quality, long working life. |
3. Feature of RO-5000 Mixed Bed Ion Exchanger Water Treatment System
| 3.1 anionic ion exchange resin use automatic control and semi-control |
| 3.2 anionic ion exchange resin has protected when no power, poor power, larger electrical current, leakage, short circuit. |
| 3.3 High Efficient anionic mixed bed ion exchange resin water treatment equipment has ISO certification and main parts accessories have obtained CE certification |
| 3.4 factory has Long term production experience. |
