SIDE PIECE

Negotiable MOQ: 5 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shanxi, China

Brand Name:

JHD

Application:

Valve body connection

Taiyuan Jiahongda Trade Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

FOB TIANJIN

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shanxi, China

Brand Name JHD

Application Valve body connection

Material Steel

Specifications

Focus on process quality & stage inspection.
The third-part inspection(TPI)
Integral test bars are taken from forgings.

Focus on process quality & stage inspection.

We are professional manufacturer of forgings and have 10 year's forgings export experience.

Material:ASTM A105 FORGED CARBON STEEL	Yield=389Mpa
UT&MPT as per ASME A355& ASME B16.34	Tensile=565Mpa
Minimum reduction ratio of product is 4:1	Elongation=30.6Mpa
Heat-treatment:Q+T	Reduction=75.0Mpa

OD:501mm

ID:195mm

H:235mm

Headness(Avg)=165HB

The mechanical property is carried out at lab authorized National.
The visual & dimension & hardness on component are inspected & tested.
All procedures of production are recorded & traceability and offer the 3.1 certificate.
According to customer demand,we would carry out the international Third-Party Inspection(TPI) and offer EN10204 3.2 Certificate.
UT & MPT are witnessed by BVIS OF TPI as per ASME A355 & ASME B16.34.
The integral test bars for mechanical property are taken from location of forings.

About us

For the forging,the material of our capability include all kinds of steel(like CC/CS/Martensitic Steel/Duplex SS)

Our company is ISO9001:2008 Certified for the production & sevice of forging steel parts of valves & flanges and design.

All procedures of making included heat-treatment are completed in our own forged shop,heat-treatment shop and machining shop.
