SIDE PIECE

SIDE PIECE thumbnail-1
SIDE PIECE photo-1
Negotiable MOQ: 5 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shanxi, China
Brand Name:
JHD
Application:
Valve body connection
Contact Supplier Request Quote Chat Now
Taiyuan Jiahongda Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB/CIF TIANJIN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shanxi, China
Brand Name JHD
Application Valve body connection
Material Steel

Specifications

Focus on process quality & stage inspection.
The third-part inspection(TPI)
Integral test bars are taken from forgings.

Focus on process quality & stage inspection.

We are professional manufacturer of forgings and have 10 year’s forgings export experience.



  1. The forgings are made of the material ASTM A350 LF2-2009.
  2. Minimum reduction ratio of product is 4:1.
  3. Heat-treament:Q+T
  4. The mechanical property is carried out at lab authorized National.
  5. Yield=325Mpa, Tensile=495Mpa, Elongation=29%, Reduction=76.5% Headness(Avg)=149HB
  6. Impact Charpy V-NOTCH at -46°C:120J Avg.(Specimen 10x10x55mm)
  7. The visual & dimension & hardness on component are inspected & tested.
  8. All procedures of production are recorded & traceability and offer the 3.1 certificate.
  9. According to customer demand,we would carry out the international Third-Party Inspection(TPI) and offer EN10204 3.2 Certificate.
  10. UT & MPT are witnessed by BVIS OF TPI as per ASME A355 & ASME B16.34
  11. The integral test bars for mechanical property are taken from location of forings.



About us



For the forging,the material of our capability include all kinds of steel(like CC/CS/Martensitic Steel/Duplex SS)

Our company is ISO9001:2008 Certified for the production & sevice of forging steel parts of valves & flanges and design.

All procedures of making included heat-treatment are completed in our own forged shop,heat-treatment shop and machining shop.

SIDE PIECE   SIDE PIECE



SIDE PIECE  SIDE PIECE
