Low loss anti-jamming 3.5Ghz 3500mhz 8dBi antenna outdoor Omni waterproof fiberglass antenna
High gain fiberglass Omni antenna,360 degree coverage!
Direct Manufacturer!
More spec. for you choose!
Can be cusomized!
All the following frequency can be customized.
(Include Antenna frequency,Gain,Connector,Cable length etc.)
Frequency Range(MHz) |
150Mhz,230Mhz,350Mhz,400Mhz,800Mhz, 900Mhz,1.2G,2.4G,3.5,5.8G |
Gain |
3dBi--15dBi |
Electrical specifications | |
Frequency Range(MHz) |
3500MHZ Omni antenna 3.5G outdoor fiberglass antenna |
Polarization |
Vertical Hign gain 3500Mhz Omni outdoor fiberglass antenna |
Impedance |
50 Ohm |
Gain (dBi) |
12db,8dBi |
Radiation |
Omni |
Horizontal Beam Width |
360º |
VSWR |
≤1.5 |
Maximum input power (W) |
50 |
Lighting Protection |
Direct Ground |
Mechanical specifications | |
Connector |
N MALE/N FEMALE |
Connector position |
Bottom |
Packing weight (kg) |
301G |
Radiating Material |
Cu |
Radome Material |
Fiberglass |
Operating temperature (℃) |
-50~70 |
Mounting hardware (mm) |
Ø25-40mm |
Shipping:
2.Express delivery: UPS / DHL / TNT / FEDEX / EMS/Air freight /Shipping to meet customers' need.
