Welding machine price list for clients benefit

FOB Price

USD $150.00 - $250.00 / Set

5 Sets(Min.Order)

Supply Ability 2000 Set / Sets per Month
Port Shenzhen

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Condition:	New	Place of Origin:	Guangdong, China	Brand Name:	DTH
Model Number:	MIG-350	Wire Feeding Speed:	2-15m/min	Dimensions:	570360535
Weight:	15kg	Usage:	Welding	Voltage:	220V
Power(W):	10.3KW-27.1KW	Certification:	ISO9001:2008	Warranty:	1 Year
After-sales Service Provided:	Engineers available to service machinery overseas

Product Description

Product Features:

1. Small and light: The size of the mid-frequency transformer in this series is reduced to only several % of that in the traditional arc welding machines. Our machines are about 1/5 ~ 1/10 as heavy and 1/3 as big as compared to the traditional ones.

2. High efficiency: Energy efficiency reaches 80~85% and power factor can reach as high as 0.93. Over 1/3 of energy is saved compared to traditional arc welders.

3. Step-less adjustment for welding current and voltage, can fulfil the requirements for different welding tasks.

4. Stable welding with little welding spatter. Nice form of welded seam.

5. Auto-compensation against power fluctuation.

6. Suitable base material: Carbon steel, Low alloy steel, Stainless steel.

Model	NBC200GS	NBC250GS	NBC250Y	NBC250G	NBC300G	NBC300Y
Input Voltage(V)	AC220V±15%	AC220V±15%	AC380V±15%	AC380V±15%	AC380V±15%	AC380V±15%
Frequency(HZ)	50/60	50/60	50/60	50/60	50/60	50/60
Rated Input Current(A)	37.4	51.6	12.7	12.7	16.8	16.7
Output Current Range(A)	40-200	40-250	50-250	50-250	50-300	50-300
Rated Output Voltage(V)	16.5-24	16.5-26.5	16.5-26.5	16.5-26.5	16.5-29	16.5-29
Duty Cycle(%)	60	60	60	60	60	60
Power Factor	0.73	0.73	0.93	0.93	0.93	0.93
Efficiency(%)	80	80	85	85	85	85
Wire Feed Type	Built-in	Built-in	Built-in	Built-in	Built-in	Built-in
Feed Speed	3-13	3-18	2.5-24	2.5-13	2.5-13	2.5-24
Housing Protection Grade	IP21	IP21	IP21	IP21	IP21	IP21
Insulation Grade	F	F	F	F	F	F
Plate Thickness(mm)	0.8+	0.8+	0.8+	0.8+	0.8+	0.8+
Shipping Weight(KG)	21	21	33	31.5	31.5	33
Packing Diameter(mm)	468245478	468245478	570295558	480204303	595.274520	570295558

Base Material	Welding Process	Wire Diameter(mm)	Current Range (A)	Applicable Model
Carbon steel Stainless steel Low-alloy steel	CO2/MAG	0.6/0.8/1.0	40-160/40-175	MIG175GD
	CO2/MAG	0.8/1.0	50-200	MIG200GS
	CO2/MAG	0.8/1.0	50-250	MIG250GS
	CO2/MAG	0.8/1.0	50-250	MIG250G
	CO2/MAG	0.8/1.0	50-300	MIG300G
