Used Engine Oil Purifier Oil Processing Machine ZJC Series

Used Engine Oil Purifier Oil Processing Machine ZJC Series thumbnail-1
Used Engine Oil Purifier Oil Processing Machine ZJC Series photo-1
US$ 6,000 - 60,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Chongqing, China
Brand Name:
Yuneng
Model Number:
ZJC-T series
Contact Supplier Request Quote Chat Now
Chongqing Yuneng Oil-Filter Manufacturing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Chongqing, China
Brand Name Yuneng
Model Number ZJC-T series
Type Other, Black Used Engine Oil Purifier Oil Processing machine

Black Used Engine Oil Purifier Oil Processing machine ZJC Series



Product Features

1. The vacuum seperation of the purifier is conducted through a separation device with an inflator. This is a new patented technology. It employs a particular stainless, foldable column for dehydration and degassing, and enlarges the area of oil separation to facilitate three-dimensional evaporation, so as to obtain enough time for degassing and to achieve the best effect of separation.



2. It uses a new-type heating equipment (Patent No. ZL02276238.8), which has a low heating load and is able to prevent oil from ageing.



3.  It uses an imported liquid ring vacuum pump and takes cooling liquid(or water) as a lubricating medium. Thus it wont matter if gas enters the vacuum pump, and users need not bother to replace the medium-functioning oil in the rotary vacuum pump.



4. Its oil level control adopts a photoelectric mode(with main components imported from Switzerland) and features a very sensitive and precise control. Even foams can be sensed, and thus there is no possibility of oil spray(Spray-free Patent No. ZL200420060973.6)



5. It uses a special high-viscosity oil feed pump and adopts a special sealing treatment. It is free from oil leakage, low in operational noise and long in useful life.



6. It also features a scientifically designed precision filtering element. In this purifier, China-made filtering elements can be inter-replaced with Italy-imported ones so that users can resort to a suitable filtering material according to the quality of different oil. Thus the use costs and oil treatment effects can be taken into balanced account.



Item

Parameter

   Type

Unit

ZJC0.6KY-T

ZJC1.2KY-T

ZJC1.8KY-T

ZJC3KY-T

ZJC6KY-T

ZJC9KY-T

ZJC12KY-T

ZJC18KY-T



Technical Parameter

Flow Rate

L/H

600

1200

1800

3000

6000

9000

12000

18000



Working Vacuity

Mpa

-0.07~-0.101



Working pressure

Mpa

≤0.35



Temperature Range

oC

45-65



Power Supply



50Hz    380V    3-Phase 4-Wire



Total Power

KW

6+1.5

9+1.5

12+1.5

30+3

2x30+4.4

3x30+6

3x30+7

4x30+11



Inlet/Outlet Diameter

mm

32/25

38/32

44/38

48/44

64/48

76/64





Size



Length

mm

1300

1300

1300

1900

1900

2100

2200

2300



Width

mm

1000

1050

1050

1400

1400

1500

1600

1700



Height

mm

1250

1450

1450

1950

2100

2150

2250

2300



Weight

Kg

320

380

450

850

1100

1500

2000

2900



Oil Treatment Index

Water Content

ppm

≤50

Kinematic Viscosity

m/s

≤20% in comparison to the original bias value of new oil

Demulsibility

min

≤15

Filtering Accuracy

µm

≤5

Cleanness

NAS

≤ Grade 6

Oil Appearance



Transparence



Black Used Engine Oil Purifier Oil Processing machine's photo for reference:

Used Engine Oil Purifier Oil Processing machine ZJC Series



Used Engine Oil Purifier Oil Processing machine ZJC Series
