Car trailer

Specifications

Large car carrier trailer
Strong and durable
Convenient to use
Different sizes are available

Spec. of car trailer



1. Surface treatment: powder coated or hot-dipped galvanized

Loading capacity: 2000KG

Floor size: 13*6.6ft (4m*2m)

Size can be also tailor made according to customers’ requirements.

Easy loading & unloading: with 2 checker plated loading ramps (3mm thick), size of each loading ramp: 400mm wide and 1500mm high



2. Material & construction:

Bolted on drawbar, RHS tube: 100*50*3mm

Trailer chassis RHS tube: 100*50*3mm

Floor: 2.5mm steel checker plate

Mudguards: 2.5mm steel checker plates

Side steps: 2.5mm steel checker plates

With square bar on the front & sides: 9.5" high at its highest point,

Square bar size: 40*40*2.5mm



3. Suspension system:

With 2 painted Axle: 50mm round solid axle, with 1 set of electric brake

Hydraulic brake is optional

Painted Leaf spring: 7-leaf eye-to-eye springs

Wheel: 4*15" wheel (powder coated steel rim+ DOT certified tire), tire size: 235/75R15

Spare wheel can be supplied at extra cost upon request



4. Standard trailer parts and accessories:

Coupling: Australian standard 50mm ball coupler, or any other type/s of coupling according to locations & requirements of overseas customers

Winch and winch bracket is optional

Safety chain: 8mm diameter in compliance with Australian standard, or to be made according to requirements of other countries’ standards

Jockey wheel: 8" solid wheel, swing up type



5. Electric Set-up

With LED tail lights (ADR certified or E-marked)

With number plate light (ADR certified or E-marked)

With wirings and 7-pin plug
