Home > Auto, Motorcycle Parts & Accessories > Car Safety > Car DVR > Support Onvif 32CH 8 SATA Port Hybrid NVR

Support Onvif 32CH 8 SATA Port Hybrid NVR

Name: Support Onvif 32CH 8 SATA Port Hybrid NVR
Brand: COOP
SKU: 103888419

Support Onvif 32CH 8 SATA Port Hybrid NVR thumbnail-1

Support Onvif 32CH 8 SATA Port Hybrid NVR photo-1

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Fujian, China

Brand Name:

COOP

Model Number:

DV9032-MF

Contact Supplier Request Quote Chat Now

Coop Security Technology(Quanzhou)Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

shipping from Xiamen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Fujian, China

Brand Name COOP

Model Number DV9032-MF

Specifications

Recording Resolution:32CH 960P/24CH 1080P/16CH 3MP/8CH 5MP
Wireless Port:3G,WiFi
Support IE,Mobile Phone Remote Monitoring

Onvif support 8pcs SATA Port 32CH Hybrid NVR

Model NO.:DV9032-MF

Feature:

Recording Resolution:32CH 960P/24CH 1080P/16CH 3MP/8CH 5MP

Recoding Frame Rate:30fps/channel

Backup way:U disk,USB,USB DVD-RM,Network storage and Backup

Support USB 2.0 Ports,IR Controller,VGA Output,HDMI Port

Support onvif,Third-party IP Cameras support

Support IE,Mobile Phone Remote monitoring

Technique Specification:

Model Number			DV-9032MF
Main processer			Industry level embedded microprocessor
System	Operating System		Embedded LINUX operating system
	Image Code Control		Image code quality adjustable, variable bitstream and constant bitstream optional
	System resource		synchronous multi-channel recording, synchronous multi-channel sub-code stream, synchronous multi-channel playback, synchronous network operation
Interface	Operation interface		16 bit true color graphical menu interface, mouse operation supportive
	display		1/4/8/9/16,24,32
Video	Video standard		1080P(1920×1080)30fps / 960P(1280×960)30ftp/720P(1280×720)30fps
	Monitoring Image Quality		1080P(1920×1080) / 960P(1280×960)/720P(1280×720)
	Video Standard		080P(1920×1080)30fps / 960P(1280×960)30ftp/720P(1280×720)30fps
	Monitoring Image Quality		1080P(1920×1080) / 960P(1280×960)/720P(1280×720)
	Image Motion Detection		Area: 396(22 *18), Sensitivity optional
	Recording Playback Quality		Any 4ch/8ch 1080P/960P/720P playback simultaneously
	Region Cover		Every channel can set 4 cover regions(IPC Support)
Recording Mode			Support manual , auto, dynamic detection, alarm trigger record mode
Backup Way			Support U disk, USB mobile HDD, USB DVD-RW, network storage and backup(Partly needs IPC Support)
Operation Way			Mouse
Local Login			User name and password
Recording Storage			Local HDD, network
External Ports		Video Input	32×(1280960)+sub[960576]+4Ref.+9Play 32ch 1.3MP IP Camera
			25x(19201080)+sub[960576]+4Ref.+4Play 24ch 2.0MP IP Camera
			16×(20481536)+sub[960576]+4Ref.+4Play 16ch 3.0MP IP Camera
			8x(25921920)+sub[960576]+4Ref.+4Play 8ch 5.0MP IP Camera
		Audio Input	32/24ch network audio input
		Video Output	1ch VGA+1ch HDMI
		Audio Output	1CH RCA(200-3000mV,5KΩ)
		Network Port	1 RJ45,10M/100M/1000M self-adaptive LAN port
		RS485 Port	1 RS485,1 RS232
		USB Port	2 USB 2.0 ports
		Alarm Input	16ch
		Alarm Output	1ch
		Wireless Port	3G,WIFI
HDD		HDD Port	8 SATA
		MAX Capacity	Each port supports MAX 4TB HDD
Mobile Surveillance			Support( iPhone, Windows Mobile, BlackBerry, Symbian, Android) smart phone
Power Supply			ATX110-220V 300W 50-60Hz
Power Consumption			≤35W)without HDD)
Working Temperature			-10℃~+55℃
Working Humidity			10%-90%
Dimension			Equipment: 440mm×450mm×90mm, Packing: 539mm×550mm×225mm
