High Quality MINI NVR KIT CCTV 720P POE 4 Channel Vandal-proof IR IP Camera NVR Kit

Name: High Quality MINI NVR KIT CCTV 720P POE 4 Channel Vandal-proof IR IP Camera NVR Kit
Brand: coopsecurity
SKU: 103888463

US$ 160 - 180 MOQ: 1 Piece

Key Specifications

Place of Origin:

China

Brand Name:

coopsecurity

Model Number:

HD-5604-POE MINI NVR KIT

Coop Security Technology(Quanzhou)Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

xiamen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin China

Brand Name coopsecurity

Model Number HD-5604-POE MINI NVR KIT

Type Digital Camera

Style Bullet Camera

Sensor CMOS

Technology Infrared

Special Features Vandal-proof

High Quality MINI NVR KIT CCTV 720P POE 4 Channel Vandal-proof IR IP Camera NVR Kit

Product Description

Model	Kit model	HP-7604-POE
Style	Feature	720P POE NVR kit
IPC specification:
System	System source	Embeded LINUX OS HI3518
Sensor	Sensor	1.0Mega Pixel, 1/4" progressive scanning CMOS
	Illumination	Color:0.1 LuxF1.2,B/W:0 LuxF1.2(IR ON) 100W
	Lens	3.6mm mega fixed lens
Others	Video compression	H.264 High profile
	Video code rate	1Mbps~6Mbps
	Resolution	Main code stream:1280720,704576;Sub code stream:704576,352288
Standard	Waterproof level	IP67
	IR distance	25-30M
	Power supply mode	NVR POE
	Communication mode	P2P
	Dimension	191× 76 × 71 mm(color: white & Grey optional)
NVR specification:
System	System source	Embeded LINUX OS HI3515
System	System source	Simultaneously multi-record/playback/users/back-up
Interface	OS	16bit real color imaging OS menu, supporting moese
Interface	Image display	1/4 picture
Video	Input	4CH 720P(1280*720)
	playback	960P/720P
	monitor	VGA:HD;HDMI:HD
	Motion detection	Support
Video playback	Recorde mode	Manual/dynamic detection/timing
	Local playback	1CH playback
	Record query	Timing/Calendar/Event/Channel query
Storge back-up	Record storage	HDD/network
Storge back-up	Back-up mode	Network back-up/USB mobile mobile hard disk
Standard	Video output	1pc VGA,1 pc HDMI 1 pc BNC,1 pc VGA
	Network interface	5pcs RJ45,10M/100M salf-adaption ethernet port, 4pcs supoorting POE
	USB interface	2pcs USB interface
	HDD interface	1pc SATA interface(MAX 4T)
	Power supply	DC15V/5A
	Dimension	Black:215(L)x215(W)x45(H)mm;White:235(L)205(W)45(H)mm
