High repeatability Winner2000B laser diffraction Sewage particle size analyzer
Application:
1. Non-metallic powders such as calcium carbonate, talcum powder, kaolin, zirconium silicate, wollastonite, graphite, silica powder, tourmaline, mica, barite, plaster, bentonite, diamond, quartz, diatomite, feldspar, calamite,clay, garnet, vermiculite, Titanium white power, etc.
2. Metallic powder such as aluminum powder, iron powder, magnesium powder, molybdenum powder, copper powder, zinc powder, other rare metal power and varied alloy powder, etc.
3. Pharmaceutical, agricultural pesticide, grinding particle, foodstuff, scientific research, teaching, cement, ceramic, glass, chemical industry, military industry, soil, pigment, oil exploration, geological analysis, river silt and electronic particle, etc.
Standard:ISO13320-1:1999, GB/T19077.1-2008, Q/JWN001-2009
Main Specification:
Model |
Winner 2000B |
Size Range |
0.1-40µm/0.6-120µm/1-300µm |
Detector channels |
32*3 |
Accuracy |
<1% (Deviation of D50 on National standard samples) |
Repeatability |
<1% (Deviation of D50 on National standard samples) |
Light source |
He-Ne Laser λ= 632.8nm p>2mW |
Ultrasonic |
F=40KHz power=35W time ≥1S |
Agitator |
0-300rpm(adjustable) |
Sample pool |
350mL |
Micro-sample pool |
10mL(Optional) |
Operation |
Key+computer control |
Test speed |
<2min |
Dimension |
L66*W32*H40cm |
N.W. |
25KG |
Working Principle:
Main Features:
1)Mie Scattering Theory
2)High efficient-cost model, semi automatic key-operation.
3)Full builtin integrated disperse system, contains Ultrasonic stirring, ultrasonic dispersion and cycling system, prevent large particle sediment in the pipe.
3)developed unconstrained free fitting technology, make particle analysis not restricted by any function, truly reflect particles distribution, ensure the good accuracy.
4)Adopt Patented converging light Fourier transform light path, efficiently improve resolution ratio of sub-micron particles.
5)Main& auxiliary detectors are fan-shaped, guarantee the effective capture of the scattered signal.
6)Three Gears test technology highly improve resolution,apply to narrow distribution.
Testing report:
Wooden box package, G.W.:40KG.
We would ship machine by DHL, FeDex, China express, by sea and by air.
Warranty: we will offer you free spare parts within 2 years, and technology support in all a life.
After warranty time, we will offer them at cost price, and shipping cost would be paid by customers.
Jinan Winner Particle Instrument Co., Ltd. have been specialized in particle size analyzer for more than 20 years since that we undertake National science Project-particle size analyzer development in 1985, We have own R&D team, sales system and after sale service team now. our particle size analyzer will enable you understand your materials well, and save your time and cost. Reliable data enables scientists, researchers and engineers to evolve formulations and processes with confidence. Our products guide research and product development, manage and control manufacturing quality, and optimize output.
By now, our products have Laser Particle size analyzer, Image particle size analyzer, Spray particle size analyzer, particles counter and Nanoparticle size analyzer etc.
We are dedicated to offer the best particle size analysis solution for you, Your satisfaction is our eternal target!
If any question, you can send INQUIRY , or CHAT with us, we will be glad to service you !
