Product Details
Place of Origin: | Guangdong, China | Brand Name: | TINCAM | Model Number: | TBC-SF4ZV1FD-FC-20 |
Product Description
1-32ch optical video converter
Technical Specification
Video channels | 1-32 channel |
Video bandwidth | 5-7.5 MHz |
Automatic compatible video system | PAL, NTSC, SECAM |
Video input / output impedance | 75 Ω |
Video signal-to-noise ratio | ≥67dB |
Differential gain | (10%-90%APL) DG <1% ( typical value) |
Differential phase | (10%-90%APL) DG <0,7% ( typical value) |
Video connector | BNC |
Fiber-optic Specification | F/O connector : FC/ST/SC Transmitter : Tx Power:-8 ~ -3dBm Sensitivity : -35dBm Receiver : Tx Power:-15 ~ -8dBm Sensitivity : -24dBm Transmission Distance :20KM (single mode) Operating Wavelength: TX1310/RX1550nm _Transmitter TX1550/RX1310nm _Receiver |
Specification of custom-made options | |
Data | Connector: Terminal Blocks Encoded type : RS485 / RS422 / RS232 / Manchester Data rate : 0 - 400Kbps BER: ≤10-9 |
Audio | Connector: Terminal Blocks Audio input / output impedance :600Ω(Balance/ unbalance) Audio input / output voltage :2Vp-p ( typical value) Audio input / output level :0dBm ( typical value) Video bandwidth:10HZ~12KHZ Audio digital encoded bandwidth :24bit Audio signal-to-noise ratio: S/N≥95dB (weighted) |
Telephone | Connector: RJ11 Bandwidth :8KHZ Features : Support call-showing function ;support H-F Operating mode : Point to point hotline mode / FXS-FXO |
Ethernet | Connector: RJ45 Support mode : Half duplex or Full duplex Standards : IEEE802.3 Data rate : 10M / 100Mbps Bandwidth: 25M |
Operating Voltage: DC5V (we will offer external power supply from AC96-240V to DC5V for each unit )
Operating Temperature: -10C to +75C
Storing Temperature : -55C to +85C
Humidity: 0 to 95% non-condensing
MTBF : ≥ 105 hours
Product package details | |
Box dimensions: | 19.2(L) x 17.3(W) x 2.8(H) mm |
Carton dimensions: | 450*400*300 mm |
Quantity/carton: | 20pairs |
Volume /carton: | 0.054 CBM |
Weight /carton: | 21-24kg |
20 container quantity | About 400PCS |
Mini order quantity: | 30pairs |
Product payment terms | |
1) Accepted small order | |
3) Ready to ship out within by sea, EMS, DHL, FedEx, as soon as we receive payment. | |
4) We accept T/T. Western Union, L/C. | |
5) Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. | |
Product warranty | |
Warranty Term | 12Months |
Return &refund terms | |
1) The items have 60days warranty. Defective products can be changed during the warranty. | |
2) Defective products must be returned within 30days from the shipping date, we will change another one for you . |
