8-port Fiber Optic Switch
Feature |
|
1) Store and forward.8k address. Support MAC address filtrate structure;
|
|
2) SW-Ring (recovery time < 20 ms at full load);
|
|
3)Port-based VLAN, IEEE 802.1Q VLAN to ease network planning;
|
|
4) Port Trunking for optimum bandwidth utilization;
|
|
5)Lock port function for blocking unauthorized access based on MAC address;
|
|
6) Port mirroring for online debugging;
|
|
7) Bandwidth management prevents unpredictable network status;
|
|
8)Dual power backup, Relay output warning for power failure and port break alarm;
|
|
9) Port link, ring fault/abnormity alarm indication;
|
|
10) IP 30 protection, rugged high-strength metal case;
|
|
11) Redundant 24VDC power input (12V~48VDC) Operating;
|
|
12) DIN-Rail or panel mounting ability.
|
Introduction |
|
TBC-MC3423-D20 series are a type of plug-and-play industrial managed redundant Ethernet switch, which supports 6 10/100Base-T(x)+2 100Base-FX interfaces. The 7 and 8 ports are used to establish SW-Ring for the purpose accomplishing redundancy for Ethernet ring network (self-recovery time <20ms) to enhance the reliability of the network. Furthermore, IES608-2F series can also support numerous intelligent network management functions, including QoS, VLAN, Port Trunking, velocity configuration and alarm enabling functions. To satisfy applications in different industrial environments, IES608-2F series can also provide wide temperature type in accommodation with limit temperature (-40 ~ 75°C).
|
Specification |
Interface |
|
RJ45 Ports 10/100BaseT(X) auto connection, Full /Half duplex or force work mode, and support MDI/MDI-X connection
|
|
Fiber Ports 100BaseFX ports (SC/ST, optional) Single-mode: 20, 40, 60, 80, 120km Multi-mode: 2km
|
|
Wavelength 850nm, 1310 nm, 1550nm
|
|
Download Program Port Based serial network management (RS-232), RJ45
|
|
Alarm output interface One relay alarm output. Support power, port link and ring network alarm
|
|
Indicator Port link, ring fault/abnormity alarm indication 10M/100M Rate, run indication
|
Technology |
|
Standard IEEE802.3, IEEE802.3x, IEEE802.3u, IEEE802.1Q, IEEE802.1D, IEEE802.1W
|
|
Transmit Rate 148810pps
|
|
Max Rate of Filtrate 148810pps
|
|
Processing Type Store and Forward
|
|
System exchange bandwidth 4.8G
|
|
Support 8K MAC address
|
|
Port-Based VLAN
|
|
|
