Specifications
Laser Engraving Machine1)with CO2 laser
2)guarantee:one year
3)compatible software
4)CE
Laser Engraving Machine
Features:
The laser adopts industrial underpan structure to ensure the stability and accuracy in high speed.
X,Y axises adopt the imported high precision straight rail, and strap transmission to ensure the processing precision..
The working table is totally chosen the enclosed stainless steel reticulation plat which special processed that will be easily operated and never be damaged.
Various informations in chinese is set on the friendly interface of the computer, and can be operated more flexibly.
Using the imported gold-plated reflector with big diameter and a 10.6um wave length, and using a ZnSe focuser with a neat focusing point.
Chosen imported aluminium material aviation frame,the structure adopt a whole design that ensure a most steady performance.
The first one adopt a USB inserting interface, which supports the insertion and pull while the computer is running, and finishes the data transmission instantly. Thus it will not take up any computer space during the engraving operation.
JOY-6090 Technology Parameter
Model |
JOY-6090 |
Laser power |
60W |
Laser type |
CO2 sealed glass laser tube,water cooling,10.6um |
Working area |
900*600mm |
Cooling |
Water-cooling |
Engraving speed |
50-24000mm/min |
Max running speed |
50000mm/min |
Cutter speed |
50-5000mm/min |
Laser energy control |
1-100% (manual and software) |
Min forming word |
Chinese:2.0*2.0mm,english:1.0*1.0mm |
Max scanning accuracy |
2500DPI |
Positioning accuracy |
≤±0.01mm |
Figure format |
DST PLT BMP DXF AI |
Glass & Cloth Laser Engraving Machine
