Specifications
1.200kva volvo generator2.ISO,CE certificate
3.reliable performance
4.global service for 12 montth
1. 200kva volvo generator specifications:
1) Output range:200kva (160kw)
2) Engine model: volvo engine
3) Alternator: Stamford
4) Water-cooled
5) 8hrs operation base tank
6) Key start / auto start
7) Sound-proof / weather-proof generator is optional
8) 230 / 400V AC, 50Hz / 60Hz, 0.8pF three-phase and four wiresalternating current output
CE approved volvo penta engine powered 200kva volvo generator
2. Technical Data:
VOLVO Diesel Engine Technical Data
Engine Model |
TAD733GE |
Configuration |
4 cycle , 6 cylinders in line |
Aspiration |
Turbochargerd |
Bore×Stroke |
108x130 mm |
Rated speed |
1500rpm |
Displacement |
7.15 L |
Compression ratio |
18.0:1 |
Prime Power |
162KW |
Speed Governor |
Electronic |
Cooling System |
water-cooled |
Speed Stability (%) |
≤5% |
Fuel Consumption at 100% Load |
213g/kw.h |
Starter Motor |
24V, |
Stamford Alternator Technical Data
Alternator model |
UCI274H |
Alternator manufacturer |
Stamford |
Exciter type |
Single bearing, Brushless, Self-excited |
Rated output prime power |
160 kW |
Rated speed |
1500 RPM |
Rated frequency |
50 Hz |
Phase |
3 |
Rated voltage |
400 V(Available with customer requirements) |
Power factor |
0.8 |
Voltage adjust range |
≥5% |
Voltage regulation NL-FL |
≤±1% |
Insulation grade |
H |
Protection grade |
IP23 |
3.Warranty:
Our warranty will be 1000 accumulative hous or 12 month after shipping, whichever comes first.
4. Document:
1) Alternator operation and maintenance manual 1PC
2)Engine operation and maintenance manual 1PC
3)Generator Overall drawings of the set 1PC
4)Electrinic system drawing 1PC
5)Bench test 1PC
6)Packing list 1PC
5.picture of control system and factory:
photos for reference:
