20% off Factory Sale 50hz 380v 150kw Silent Diesel Generators

US$ 10,000 - 25,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

Model Number:

CCFJ150JW

Taizhou Fengde Mechanical & Electrical Manufacturing Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name JG

Model Number CCFJ150JW

Output Type AC Three Phase

Speed 1500rpm/1800rpm

Frequency 50hz/60hz

Rated Power 150kw

Rated Voltage 230v/380v

Rated Current 270A

Specifications

1.150kw silent diesel generators
2.ISO,CE certificate
3.global service for 12 month
4.75dB at the distance of 7 meters

1. 150kw silent diesel generators general feature:

1) Output range:150kw(188kva)

2) Engine model: cummins engine

3) Alternator: Marathon,Stamford,ENGGA,leroy somer is optional

4) Water-cooled

5) 8hrs operation base tank

6) Key start / auto start

7) Sound-proof / weather-proof generator is optional

8) 230 / 400V AC, 50Hz / 60Hz, 0.8pF three-phase and four wiresalternating current output

We are the top VIP supplier on Alibaba ,

authorized by famous certification authority-BV ( Bureau Veritas ).

20% off factory sale 50hz 380v 150kw silent diesel generators

2.Cummins diesel generator Technical Data:

1.Main technical data of soundproof gensets
1.1	Model	JGC150GF
1.2	Prime power	150KW/183KVA
1.3	Prime voltage	230/400V
1.4	Speed	1500 rpm
1.5	Weight	1000kg
1.6	Overall dimension	1670×850×1270mm (just for reference)
2.Main technical data of engine
Cummins engine, 4 stroke. DC start.
2.1	Brand	CUMMINS
2.2	Model	6CTA8.3-G2
2.3	Prime power	47KW
2.4	Governor type	Electronic
2.5	Configuration	4 cycle , 6 cylinder in line
2.6	Air Intake System	Tubocharged/After cooler
2.7	Bore/Stroke	102×120mm
2.8	Displacement	3.9 L
2.9	Starting method	Electric
2.10	Compression ratio	15:1
2.11	Fuel consumption	201g/kw.h
3. Main technical data of alternator
Alternator is selected the new type brushless alternator designed by US Marathon Electric, which has a unique design, advanced structure, small size, light weight, excellent performance, reliable running and easy-to-use operation.
3.1	Brand	MARATHON
3.2	Model	MP-150-4
3.3	Prime power	40KW
3.4	Configuration	Brushless , self-exciting
3.5	Prime voltage	230V/400V
3.6	Frequency	50 HZ
3.7	Power factor	0.8(lagging)
3.8	Phase/wire	3 phase 4 wires
3.9	Isolation	H
