Home > Products > Soundproof Generator > Factory Direct Sale Silent Generator 30kva
Factory Direct Sale Silent Generator 30kva
- shanghai
- T/T L/C D/P D/A
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | JG | |
| Model Number | JGC24GF | Output Type | AC Three Phase | |
| Speed | 1500rpm/1800rpm | Frequency | 50hz/60hz | |
| Rated Power | 24kw | Rated Voltage | 400V/440V | |
| Rated Current | 54A |
Product Description
Specifications
1.silent generator 30kva2.global service for 12 month
3.ISO,CE certificate
4.75dB at the distance of 7 meters
1. silent generator30kva general feature:
1) Output range: 30kva
2) Engine model: 4BT3.9-G2
3) Alternator: Stamford, Marathon series Stamford copy
4) Water-cooled
5) 8hrs operation base tank
6) Key start / auto start
7) silent generator is optional
8) 230 / 400V AC, 50Hz / 60Hz, 0.8pF three-phase and four wiresalternating current output
9) Frequency: <3%
10) Frequency at stable state: <0.5%
11) Frequency deviation at instantaneous state: ≤+10%
12) Frequency return time: ≤3s
13) Voltage deviation at stable state: ≤±1%
14) Voltage deviation at instantaneous state: ≤+20%15) Voltage return time: ≤4s16) Voltage modulation: ≤0.3%
We are the top VIP supplier on Alibaba ,
authorized by famous certification authority-BV ( Bureau Veritas ).
2.Diesel GeneratorTechnical Data:
Cummins Diesel Engine Technical Data
Engine model | 4B3.9-G2 |
Engine manufacturer | Cummins |
Number of cylinders | 4 |
Cylinder arrangement | Vertical in-line |
Cycle | Four stroke |
Aspiration | Naturally |
Bore×Stroke (mm×mm) | 102 x 120 |
Displacement (Liter) | 3.9 |
Compression Ratio | 16.5:1 |
Prime power/speed (kW/RPM) | 24/1500 |
Standby power/speed (kW/RPM) | 27/1500 |
Speed governor | Electrical |
Cooling system | Forced Water Cooling Cycle |
Steady speed droop (%) | ≤1% |
Total lubrication system capacity (L) | 11 |
Coolant capacity (engine only) (L) | 7.2 |
Fuel consumption at 100% load (g/kWh) | 229 (at 1500RPM) |
Starter motor | DC24V, |
Alternator | DC24V |
Marathon Alternator Technical Data
Alternator model | GM-20-4 |
Alternator manufacturer | Marathon |
Exciter type | Single bearing, Brushless, Self-excited |
Rated output prime power | 20 kW |
Rated speed | 1500 RPM |
Rated frequency | 50 Hz |
Phase | 3 |
Rated voltage | 400 V(Available with customer requirements) |
Power factor | 0.8 |
Voltage adjust range | ≥5% |
Voltage regulation NL-FL | ≤±1% |
Insulation grade | H |
Protection grade | IP23 |
3.Warranty:
Our warranty will be 1000 accumulative hous or 12 month after shipping, whichever comes first.
4.Certificate & Document:
1) Alternator operation and maintenance manual 1PC
2)Engine operation and maintenance manual 1PC
3)Generator Overall drawings of the set 1PC
4)Electrinic system drawing 1PC
5)Bench test 1PC
6)Packing list 1PC
5.picture of control system and factory:
picture for reference
