BV,DNV Approved 200hp Marine Diesel Engine With Gear Box Gear for Ship

BV,DNV Approved 200hp Marine Diesel Engine With Gear Box Gear for Ship photo-1
BV,DNV Approved 200hp Marine Diesel Engine With Gear Box Gear for Ship photo-2
BV,DNV Approved 200hp Marine Diesel Engine With Gear Box Gear for Ship photo-3
US$ 5,000 - 25,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
JG
Model Number:
JGC141GF
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Jiangsu, China
Brand Name JG
Model Number JGC141GF
Output Type AC Three Phase
Speed 1500rpm/1800RPM
Frequency 50hz/60hz
Rated Power 141kw
Rated Voltage 230v/400v
Rated Current 253A

Specifications

1.marine diesel engine with gear box gear
2.ISO,CE,BV certificate
3.one year warranty
4.global service for12 month

1. Mairne engine general feature:

1.Engine model :WD150C15
2.High quality
3.BV class and Tier Ii emission
4.Competitive price

It has advantages of compact structure, high reliability, high economic performance, easy operation and maintenance. This series engine, as main or auxiliary engine, are chiefly mounted on small-size transport ships and fishing boats on inland rivers.

We are the top VIP supplier on Alibaba ,

authorized by famous certification authority-BV ( Bureau Veritas ).

  BV,DNV approved 200hp marine diesel engine with gear box gear for ship

Specifications

2. Technical Data:



Parameters of 200HP marine engine:



Engine Model WD150C15
Engine Type In-Line, Direct Injection.
Cylinder No. 6
Bore* Stroke (mm) 140*160
Displacement 14.77 L
Piston Speed (m/s) 8
Compression
Ratio
17
Rated Speed 1500
Rated Power (KW/HP) 141/192
Max Power 155/211
Fuel Consumption (g/kw.h) < 199
Lub Oil Consumption (g/kw.h) < 0.67
Ignition Order 1-5-3-6-2-4
Cooling Method Closed Water cooled (with Sea-Water Heat Exchanger)
Aspiration Type Natural
Start Method 24V Electric





  1. Engine

operation and maintenance manual

 BV certificate

 TIER2 certificate





1PC

1PC

1PC

3.Warranty:

 Our warranty will be 1000 accumulative hous or 12 month after shipping, whichever comes first.

4.Picture:

BV,DNV approved 200hp marine diesel engine with gear box gear for ship

We will be your best partner!!!

 Do not hesitae any more!!!!

  Contacts:Ms Vicki Yuan

  Skype:vicki_yuan90

 BV,DNV approved 200hp marine diesel engine with gear box gear for shipBV,DNV approved 200hp marine diesel engine with gear box gear for shipBV,DNV approved 200hp marine diesel engine with gear box gear for shipBV,DNV approved 200hp marine diesel engine with gear box gear for shipBV,DNV approved 200hp marine diesel engine with gear box gear for ship
