Good Quality and Hot Sale Shangchai Marine Diesel Generator With CE Approved

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

Model Number:

CCFJ90YY

Taizhou Fengde Mechanical & Electrical Manufacturing Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name JG

Model Number CCFJ90YY

Output Type AC Three Phase

Speed 1500rpm

Frequency 50HZ

Rated Power 90kw

Rated Voltage 380V

Rated Current 162A

Good quality and hot sale shangchai marine diesel generator

Marine generator

shangchai marine diesel generator set

Engine
Brand	SHANGCHAI
Model	6135ACaf
Configuration	4 cycle, 6 cylinder in lin
Aspiration	Tubocharged
Output	Rated output	Standby output
	111.3KW	122.4KW
Bore and Stroke	135×150mm
Rated Speed , rpm	1500
Displacement	12.0L
Fuel consumption	≤205g/kw.h
Starting method	24 Voltage DC , electric
Engine filter system	Dry type air filter, double fuel filter, oil filter, coolant filter

shangchai marine diesel generator set

Alternator
Brand	LANDIAN
Model	TFXW-250M4-H
Capacity	Rated output	Standby output
	90KW/112KVA	99KW/124KVA
Voltage	380V/220V
Frequency & speed	50HZ / 1500rpm
Power factor	0.8(lag)
Exciter type	Brushless , self-excitingh
Ambient temp.	-15-55
Phase and wire	3 phase and 4 wires
Isolation level	H
Auto voltage regulators(AVR)	An Electronic AVR with 3 phase , sensing for regulations of 0.5% or better and improved Performance is need , following control to be included in the AVR. a)Voltage drop b)Voltage level c)Voltage gain d)Shut down indicators
Protection class	IP21
Voltage regulation , steady state	≤±1%
