Good Choice!!! Yangdong Engine Slient Diesel Generator for Sale 20kva
Specifications
good choice!!! yangdong engine slient diesel generator for sale 20kva1.rated power:20kva
2.Vol /Fre: 230/400V 50Hz
good choice!!! yangdong engine slient diesel generator for sale 20kva
| Product Overview | |
| 1) Brand-new engine,w/start motor. | |
| 2) Brushless alternator,single bearing,flange connection,IP23,H insulation class,with AVR. | |
| 3) Auto control panel with LCD display. | |
| 4) Engine mounted battery-charging alternator,Genset with battery charge of main supply. | |
| 5) Circuit Breaker,Exhaust Silencer. | |
| 6) Copper Radiator for 40°C ambient temperature and double-deck cooling,with fan guard and front guard. | |
| 7) Anti-vibration pads fixed between engine/alternator and base frame to ensure the compete genset running stable. | |
| 8) Skid-mounted bottom 8 hours fuel tank. | |
| 9) Extemal recessed emergency stop button for extra safety. | |
| 10)Optional:Soundproof,ATS(automatic transfer switch),AMF panel,Trailer,Parallel system. | |
| 20Kva Yangdong diesel generator | |
| Genset Specification | |
| Genset Model | BY-20 |
| Prime Power(Kw/Kva) | 1620 |
| Frequency | 60Hz |
| Structure type | Open or Soudproof |
| Dba"@7m | silent genset 55-78 dba @ 7m , open type75-98 dba @7m |
| Engine Model | YND485D |
| Alternator Model | STG164D |
| Open type DimensionL*W*H(mm) | 1700x700x900 |
| Weight(Kg) | 700 |
| Silent type DimensionL*W*H(mm) | 1830x880x950 |
| Weight(Kg) | 800 |
| Engine Detail | |
| Manufacturer | Yangdong engine Co.,Ltd |
| Model | Y385D |
| Engine speed | 1800rpm |
| Engine power | |
| …………Prime power | 20KW(60Hz) |
| Type | vertical,4 cylinder,in-line,water-cooled,four-stroke |
| Aspiration | Naturally aspirated |
| Governor | electrical |
| Bore*Stroke | 85*95mm |
| Alternator Detail | |
| Model | STG164D |
| Output power(Kw/Kva) | 1620 |
| Number of phase | 3 |
| Power factor(Cos Phi) | 0.8 |
| Number of Pole | 4 |
| Exciter type | Shunt |
| Insulation class | H |
| Voltage regulation | 0.50% |
| Total haarmonics (TGH/THC) | 4% |
| Wave form:Nema=TIF | 50 |
| Wave form:I.E.C=THF | 2% |
| Bearing | single |
| Coupling | Direct |
Generator soundproof/Silent and canopy
Ø Excellent ventilation
Ø Black finish stainless steel locks and hinges
Ø Zinc plated or stainless steel fasteners
Ø Body made from steel components treated with polyester powder coating
Ø Two large doors on either side
Ø Radiator fill access plate
Ø Fully guarded cooling fan and battery charging alternator
Ø Fuel fill and battery access via lockable access doors
Ø Emergency stop button on canopy exterior
Ø Lube oil drain and radiator drain to exterior
Ø Control panel viewing window
Ø Lifting points on base frame
Ø 1m<80DBA / 7m<70DBA
Generator set warranty and maintenance:
Ø Do the full power load test for five hours before package.
Ø One year or 1000 working hours, whichever comes first, global warranty for Cummins. Deutz, UK P, Volvo, Daewoo.
Ø After expiration, we provide spare parts maintenance with low price
Slient yuchai power generator
Stamford alternator of generator
Controller
Factory
Exhibition
Certificate
