Slient yuchai price of 60kva generator

Specifications

Slient yuchai price of 60kva generator
1.Vol /Fre: 230/400V 50Hz
2.Power factor: 0.8
3.slient

  Slient yuchai price of 60kva generator





Product Overview
1) Brand-new engine,w/start motor.
2) Brushless alternator,single bearing,flange connection,IP23,H insulation class,with AVR.
3) Auto control panel with LCD display.
4) Engine mounted battery-charging alternator,Genset with battery charge of main supply.
5) Circuit Breaker,Exhaust Silencer.
6) Copper Radiator for 40°C ambient temperature and double-deck cooling,with fan guard and front guard.
7) Anti-vibration pads fixed between engine/alternator and base frame to ensure the compete genset running stable.
8) Skid-mounted bottom 8 hours fuel tank.
9) Extemal recessed emergency stop button for extra safety.
10)Optional:Soundproof,ATS(automatic transfer switch),AMF panel,Trailer,Parallel system.
Genset Specification
Genset Model	BYC-60
Prime Power(Kva/Kw)	50KW/63KVA
Structure type	Open/Silent
Dba"@7m	silent genset 55-78 dba @ 7m , open type75-98 dba @7m
Engine Model	YC4D75Z-D20
Alternator Model	STG224D
DimensionL*W*H(mm)
Open Type	2360*880*1530
Weight	1400
Silent Type	2460*980*1630
Weight(Kg)	1450
Engine Detail
Engine Brand	Yuchai Diesel engine
Model	YC4D75Z-D20
Engine speed	1800rpm
Engine power
…………Standby power	55KW
…………Prime power	50KW
Type	4cycle,in-line,6-cylinder
Aspiration	Turbocharged,
Governor	electrical
Bore*Stroke	108*115mm
Displacement	4.214 Litres
Compression ratio	17.5:1
Alternator Detail
Manufacturer	Fuzhou Boomaster Power Co.,Ltd
Model	STG224D
Output power	50KW
Number of phase	3
Power factor(Cos Phi)	0.8
Altitude	≤1000m
Overspeed	2250rpm
Number of Pole	4
Exciter type	Shunt
Insulation class	H
Voltage regulation	±0.5%
Sustained short circuit current	300%(3IN):10s
Total haarmonics (TGH/THC)	<4%
Wave form:Nema=TIF	<50
Wave form:I.E.C=THF	<2%
Bearing	single
Coupling	Direct





Generator soundproof/Silent and canopy



Ø   Excellent ventilation

Ø   Black finish stainless steel locks and hinges

Ø   Zinc plated or stainless steel fasteners

Ø   Body made from steel components treated with polyester powder coating

Ø  Two large doors on either side

Ø   Radiator fill access plate

Ø   Fully guarded cooling fan and battery charging alternator

Ø   Fuel fill and battery access via lockable access doors

Ø   Emergency stop button on canopy exterior

Ø   Lube oil drain and radiator drain to exterior

Ø   Control panel viewing window

Ø   Lifting points on base frame

Ø   1m<80DBA / 7m<70DBA



Generator set warranty and maintenance:



Ø   Do the full power load test for five hours before package.

Ø   One year or 1000 working hours, whichever comes first, global warranty for Cummins. Deutz, UK P, Volvo, Daewoo.

Ø   After expiration, we provide spare parts maintenance with low price



Slient yuchai power generator







Stamford alternator of generator





Controller







Factory



Exhibition





Certificate
