10kva Yanmar Diesel Generator Set
US$ 1,999 - 19,999
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
Boomaster
Model Number:
BM11YM5
Payment & Shipping
Payment Methods:
Port of Shipment:
Any port of China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
the Best Price for 25kva Yanmar Diesel Generator Small GeneratorUS$ 2,000 - 2,500MOQ: 1 Set -
2013 Hot Sales! Brushless Yanmar Generator 14.5kvaUS$ 4,465 - 5,800MOQ: 1 Set
-
10KW Diesel Yanmar Generator With Soundproof Canopy 50hzUS$ 4,465 - 5,800MOQ: 1 Set
-
Boomaster Yanmar Diesel Generator Yanmar GeneratorsUS$ 4,465 - 5,800MOQ: 1 Set
-
Welder Model TS350SXY With Yanmar EngineUS$ 7,250 - 7,850MOQ: 1 Set
Place of Origin
Fujian, China
Brand Name
Boomaster
Model Number
BM11YM5
Output Type
AC Three Phase
Speed
1500/1800rpm
Frequency
50HZ
Rated Power
10KVA
Rated Voltage
230/400V
Rated Current
14A
Specifications
Yanmar Diesel Generator Set1)water-cooled
2)Delivery Time:20 Days
3)Payment:L/C,T/T
4)CE,EPA approval
Product Overview
1) Brand-new engine,w/start motor.
2) Brushless alternator,single bearing,flange connection,IP23,H insulation class,with AVR.
3) Auto control panel with LCD display.
4) Engine mounted battery-charging alternator,Genset with battery charge of main supply.
5) Circuit Breaker,Exhaust Silencer.
6) Copper Radiator for 40°C ambient temperature and double-deck cooling,with fan guard and front guard.
7) Anti-vibration pads fixed between engine/alternator and base frame to ensure the compete genset running stable.
8) Skid-mounted bottom 8 hours fuel tank.
9) Extemal recessed emergency stop button for extra safety.
10)Optional:Soundproof,ATS(automatic transfer switch),AMF panel,Trailer,Parallel system.
| Genset Specification | |
| Genset Model | BM11YM5(50Hz) |
| Prime Power(Kva/Kw) | 8Kw/10Kva(50Hz) |
| Engine Model | YANMAR 3TNV82A |
| Alternator Model | PI044E(50Hz) |
| Speed Control type | Centrifugal-all speed governor |
| Phase | Three |
| Fuel Tank Capacity | 50 L |
| System Voltage | 12V |
| Frequency | 50/60 Hz |
| Fuel injection pump | Bosch in-line, Yanmar made |
| Emission level | Stage 4 |
| Dimension(L*W*H mm) | |
| Open Type | 1460*730*1170 |
| Silent Type | 1800*740*1150 |
| Engine Detail | |
| Model | YANMAR 3TNV82A |
| Maximum output(kw) | 11KW(50Hz) |
| Number of Cylinders | 3 |
| Aspiration | Naturally aspirated |
| Cycle | 4 |
| Fuel Type | Diesel |
| Combustion Type | Indirect Injection |
| Cooling Type | Water cooled |
| Coolant Capacity | 1.8 liter |
| Lubrication Capacity | 5.5 liter |
| Bore*Stroke | 82*86mm |
| Displacement | 1.331 L |
| Compression ratio | 19.2:1 |
| Alternator Detail | |
| Model | PI044E(50Hz) |
| Insulation | Clase"H" |
| Execitation Type | Self-excitation |
| Protection class | IP23 |
