Boomaster Yanmar Diesel Generator Yanmar Generators

Name: Boomaster Yanmar Diesel Generator Yanmar Generators
Brand: Yanmar
SKU: 103713261
Availability: InStock

Elephant Tech Fuzhou Co., Ltd.

US$ 4,465 - 5,800 MOQ: 1 Set

Key Specifications

Place of Origin:

Fujian, China

Brand Name:

Yanmar

Model Number:

BM54YM5

Payment & Shipping

Payment Methods:

Port of Shipment:

Fuzhou Port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Fujian, China

Brand Name Yanmar

Model Number BM54YM5

Output Type AC Three Phase

Speed 1,500rpm

Frequency 50Hz/60Hz

Rated Power 39KW

Rated Voltage 220V/380 230V/400V

Rated Current 127.94A

Specifications

Boomaster yanmar diesel generator yanmar generators
1.Fuel type: Diesel
2.Aspiration:Naturally aspiratede
3.Cycle: 4

Boomaster yanmar diesel generator yanmar generators

Product Overview

1) Brand-new engine,w/start motor.

2) Brushless alternator,single bearing,flange connection,IP23,H insulation class,with AVR.

3) Auto control panel with LCD display.

4) Engine mounted battery-charging alternator,Genset with battery charge of main supply.

5) Circuit Breaker,Exhaust Silencer.

6) Copper Radiator for 40°C ambient temperature and double-deck cooling,with fan guard and front guard.

7) Anti-vibration pads fixed between engine/alternator and base frame to ensure the compete genset running stable.

8) Skid-mounted bottom 8 hours fuel tank.

9) Extemal recessed emergency stop button for extra safety.

10)Optional:Soundproof,ATS(automatic transfer switch),AMF panel,Trailer,Parallel system.

Genset Model	BM54YM5(50Hz)
Prime Power(Kva/Kw)	39Kw/49Kva(50Hz)
Engine Model	YANMAR 4TNV106
Alternator Model	UCI224D(50Hz)
Speed Control type	Centrifugal-all speed governor
Phase	Three
Fuel Tank Capacity	220L
System Voltage	12V
Frequency	50/60 Hz
Fuel injection pump	Bosch in-line, Yanmar made
Emission level	Stage 4
Dimension(LWH mm)
Open Type	19107301170
Silent Type	22507401150

Engine Detail
Model	YANMAR 4TNV106
Maximum output(kw)	49.4KW(50Hz)
Number of Cylinders	4
Aspiration	Naturally aspirated
Cycle	4
Fuel Type	Diesel
Combustion Type	Indirect Injection
Cooling Type	Water cooled
Coolant Capacity	6liter
Lubrication Capacity	14 liter
Bore*Stroke	106*125mm
Displacement	4.412 L
Compression ratio	18:01

Alternator Detail
Model	UCI224D(50Hz)
Insulation	Clase"H"
Execitation Type	Self-excitation
Protection class	IP23

Generator optional:

Engine	Heater	Battery Charger
Fuel System	Daily Fuel Tank	Base Fuel Tank
Control System	Auto Control Panel	Remote Control Panel	Auto Transfer Switch (ATS) Control Panel
Alternator	Single phase, three phase	Brushless, carbon brush
Type	Weatherproof Type	Soundproof Type	Trailer type
Spare Parts	Fuel filer, Oil filter, air filter, tank pad, Triangle Belt, tools and Engine Parts Drawing List
