Small Boiler Thermal Oil Boiler Coal Boiler
A: Features of coal-fired thermal oil heater
1. Low steel consumption,high air leakage efficient, high coal leakage volume,
suitable to burn I II soft coal
2. Adoption of automatic temperature control function is made to achieve stable
heating and precise temperature adjustment.
3. It adopts perfect running control and safety monitoring device with safety,reliability
and easy operation.
4. Fast temperature rise,high thermal efficiency, with overload capacity at a certain
degree to ensure output of boiler.
B: Parameter coal fired thermal oil heater
| Horizontal China Grate Coal-fired Thermal Oil Boiler | ||||||||||||||||
| Model |
YLW-1900 MA-160 |
YLW-2300 MA-200 |
YLW-3000 MA-250 |
YLW-3500 MA-300 |
YLW-4000 MA-350 |
YLW-4600 MA-400 |
YLW-6000 MA-500 |
YLW-7000 MA-600 |
YLW-8000 MA-700 |
YLW-9300 MA-800 |
YLW-10000 MA-900 |
YLW-12000 MA-1000 |
YLW-14000 MA-1200 |
YLW-16500 MA-1400 |
YLW-19000 MA-1600 |
|
| Rated Power | KW | 1900 | 2300 | 3000 | 3500 | 4000 | 4600 | 6000 | 7000 | 8000 | 93000 | 10000 | 12000 | 14000 | 16500 | 1900 |
| x104 kcal/h | 160 | 200 | 250 | 300 | 350 | 400 | 500 | 600 | 700 | 800 | 900 | 1000 | 1200 | 1400 | 1600 | |
| Design Thermal Efficiency(%) | >=79 | |||||||||||||||
| Rated Working pressure | 1 | |||||||||||||||
| Max. Working temperature | 320 | |||||||||||||||
| Thermal Oil Capacity | 2.8 | 3.5 | 4.85 | 5.4 | 5.8 | 6.8 | 7.9 | 8.8 | 9.8 | 13.5 | 14.8 | 15.6 | 16.9 | 18.1 | 19.4 | |
| Circulation oil capacity (m3/h) | 165 | 200 | 225 | 280 | 280 | 300 | 340 | 400 | 400 | 520 | 600 | 680 | 800 | 800 | 800 | |
|
Main valve size |
DN150 | DN150 | DN150 | DN200 | DN200 | DN200 | DN250 | DN250 | DN250 | DN300 | DN325 | DN350 | DN350 | DN400 | DN400 | |
| Whole system power KW | 75 | 85 | 85 | 130 | 130 | 150 | 180 | 205 | 205 | 260 | 280 | 310 | 315 | 320 | 350 | |
| Available fuel | AI, AII, AIII soft coal | |||||||||||||||
| Weight (KG) | 21500 | 23000 | 24000 | 29500 | 32000 | 35000 | 45000 | 64000 | 66500 | 66800 | 87600 | 98000 | 128500 | 146000 | 168000 | |
D: Details about coal fired thermal oil heater
Q: Are you manufacturer?
A: Yes, we are manufacturer. Our factory is in Pingdu Qingdao established in 1993.
Q: Do I get guarantee of products?
A: Yes, every product is 1 year quality warrantee under customer correct using the products.
Q: Do you have any Certificate?
A: Yes. Each of our boiler has China GB certificate. If you need CE ASME or AS, we can help you to get it.
Q: How to buy it?
A: Please contact me by email or online, let me know your factory situation, I will give you some advice which model mostly suitable to you.
Q: What about the delivery?
A: We have shipping agent that can choose the cheapest and fastest delivery. FOB,CIF, C&F or EXW are no problem for us
Q: How can I pay you?
A: T/T, LC is very well used.
Q: What about the production?
A: Produce time is 20~25days for <6Ton boiler, 25~40days for >8Ton boiler.
Q: Could you offer some wear parts?
A: Yes, some chain grate bars, electric equipments in control panel box for example.
Q: What about the maintenance?
A: I will offer you the timely maintenance way after installation of the boiler mainly parts.
|
|
