YYQ(W) Series Gas and Oil Fired Heater Thermal Oil Boiler for Sales
Dear Customer:
Welcome to our website and hope our products will make you satisfied .
We think creatively,design bravely,manufacture precisely and loyalty to
our customers. And we have our own We can produce the products
according to customer requirements .
Give us a negotiate chance will yield you a surprise .
Yours
EPCB
Specification
1.Large heating surface thermal oil boiler thermal oil boiler
2.High thermal efficiency natural gas fired thermal oil boiler natural gas fired thermal oil boiler
3.Precise temp. control double coils natural gas fired thermal oil boiler
4.Clean combustion, less pollution double coils natural gas fired thermal oil boiler
Description
This series of heat conduction furnace is with compact structure, stylish design,good performance and simple operation. Hence, it is widely used in such industries
as textiles, printing, chemicals, plastics, painting, synthetic fibers manufacturing,rubber production, shipbuilding and foodstuff processing.
1. The system of thermal oil boiler is more sample than steam boiler.
2. The position between the burner joint and the coil is sealed with good seal, large flexible space, to increase the service life of burner and enhance the heating efficiency.
3. It adopts perfect running control and safety monitoring device with safety, reliability and easy operation.
4. Fast packaged or assembled for shipment with easy transportation, short installation period, and fast return of Investment.
5. The boiler features heat preservation performance with high-efficiency heat preservation material and state-of-the-art construction technology, lower radiating loss of boiler wall.
6. Fast temperature rise, high thermal efficiency, with overload capacity at a certain degree to ensure output of boiler.
7. No black smoke escapes to help achievement of environmental protection.
8. Outstanding energy-saving effect, saving energy by 10-15% compared with similar products, return of investment for the equipment in the whole boiler room may be attained by capital of saved energy for one year operation.
| YY(Q)W Type of Horizontal oil (gas)-fired Thermal oil Boiler | ||||||||||||
| Model |
Y(Q)W- 180-Y(Q) |
Y(Q)W- 350-Y(Q) |
Y(Q)W- 600-Y(Q) |
Y(Q)W- 1200-Y(Q) |
Y(Q)W- 1800-Y(Q) |
Y(Q)W- 2400-Y(Q) |
Y(Q)W- 3000-Y(Q) |
Y(Q)W- 4000-Y(Q) |
Y(Q)W- 6000-Y(Q) |
Y(Q)W- 9600-Y(Q) |
Y(Q)W- 12000-Y(Q) |
|
| Rated thermal power | KW | 180 | 350 | 600 | 1200 | 1800 | 2400 | 3000 | 4000 | 6000 | 9600 | 12000 |
| ×104kcal/h | 15 | 30 | 50 | 100 | 150 | 200 | 250 | 350 | 500 | 800 | 1000 | |
| Design thermal efficiency (%) | ≥83 | ≥83 | ≥83 | ≥85 | ≥85 | ≥85 | ≥85 | ≥86 | ≥88 | ≥88 | ≥88 | |
| Rated working pressure (MPa) | 1.0 | 1.0 | 1.0 | 1.0 | 1.0 | 1.0 | 1.0 | 1.0 | 1.0 | 1.0 | 1.0 | |
| Max. working temperature (℃) | 320 | 320 | 320 | 320 | 320 | 320 | 320 | 320 | 320 | 320 | 320 | |
| Thermal oil capacity (m³) | 0.15 | 0.32 | 0.44 | 0.86 | 1.48 | 2.2 | 3.5 | 4.9 | 7.2 | 9.6 | 12.6 | |
| Circulation oil capacity (m³/h) | 18 | 30 | 60 | 100 | 150 | 200 | 200 | 230 | 300 | 500 | 580 | |
| 60#heavy oil (Kg/h) | 20 | 40.2 | 67 | 134 | 203 | 270 | 338 | 472 | 672 | 1080 | 1350 | |
| Diesel (Kg/h) | 19 | 39 | 65 | 130 | 196 | 260 | 326 | 454 | 650 | 1043 | 1302 | |
| Natural gas (Nm³/h) | 23 | 47 | 79 | 158 | 236 | 315 | 395 | 555 | 790 | 1265 | 1583 | |
| Liquefied petroleum gas(Nm³/h) | 7.7 | 15.3 | 26 | 51 | 77 | 103.5 | 130 | 178 | 260 | 415 | 521 | |
| Max. transport size | L (mm) | 1500 | 2300 | 2920 | 4100 | 4400 | 4700 | 4980 | 6190 | 6480 | 6850 | 7100 |
| W (mm) | 1100 | 1450 | 1560 | 2000 | 2300 | 2600 | 2650 | 2920 | 3150 | 3780 | 4050 | |
| H (mm) | 1500 | 1680 | 1790 | 2250 | 2550 | 2850 | 3150 | 3360 | 3400 | 4260 | 4600 | |
| weight (t) | 1.5 | 2.7 | 3.9 | 7.5 | 10 | 12.9 | 17.5 | 20.8 | 42.5 | 59 | 63 | |
| Chimney diameter | 250 | 300 | 350 | 400 | 400 | 500 | 500 | 650 | 700 | 850 | 1000 | |
Our Services:
1. 100%safety, running stably, excellent water level and pressure control, fully automatic operation.
2. Boiler running life > 20years.
3. Good after-sale service. It is free for you to get the damaged spares in warranty period (1 year) if there is any question. Assure that we can supply you spares in boiler’s all life.
4. We can arrange engineer to your company for installation and commissioning and training. If you need us at any time, we can send our technicians and prepare in a short time.
5. Special paint is used after assembly. Paint is particularly used in your climate area, which is anti-corrosion, anti-abrasion and color-fastness.
Why do you choice our boiler?
1. Lower dust emission & SO2 emission & NOx emission, dust emission concentration < 30mg/m³
SO2 & NOx emission concentration < 18mg/m³
2. We supply 2 units Water Pump (one duty one standby) which from the famous pump manufacturer.
3. Boiler can achieve automatic temperature control & pressure control & feed water control & feed fuel control & safety indication.We also freely supply you a set of inner parts of Electric controller for standby.
4. Boiler with stainless cladding, anti-corrosion & anti-rust & beautiful appearance.
5. Comprehensive after-sales service. We can design layout drawings of boiler system according to your actual requirement.Also can dispatch engineer to guide installation & commissioning.
Q: Are you manufacturer?
A: Yes, we are manufacturer. Our factory is in Pingdu Qingdao established in 1993.
Q: Do I get guarantee of products?
A: Yes, every product is 1 year quality warrantee under customer correct using the products.
Q: Do you have any Certificate?
A: Yes. Each of our boiler has China GB certificate. If you need CE ASME or AS, we can help you to get it.
Q: How to buy it?
A: Please contact me by email or online, let me know your factory situation, I will give you some advice which model mostly suitable to you.
Q: What about the delivery?
A: We have shipping agent can choosing the cheapest and fastest delivery. FOB,CIF, C&F or EXW are no problem for us
Q: How can I pay you?
A: T/T, LC is very well used.
Q: What about the production?
A: Produce time is 20~25days for <6Ton boiler, 25~40days for >8Ton boiler.
Q: Could you offer some wear parts?
A: Yes, some chain grate bars, electric equipments in control panel box for example.
Q: What about the maintenance?
A: I will offer you the timely maintenance way sheet after installation of the boiler mainly parts.
High Quality with Mature Design:
1. Quality:
A grade boiler, A1, A2 grade pressure vessel manufacturing company. All products have passed ISO9001:2008 & ASME International Quality Management System Certification, also can provide CE, AS, GOST certification.
2. Management:
In order to ensure the quality, we strictly monitor the comprehensive quality system from raw material procurement & re-testing & process to storage. All the steels and pipes are purchased from developed countries & the well-known large domestic enterprises.
3. Welding:
Welding mainly uses advanced automatic welding, gas protected welding, TIG welding. Drum and other main pressure parts adopt CNC automatic welding, all of the welding 100% passed penetrant inspection.
4. Market:
Asia: Kazakhstan, Uzbekistan, Kyrgyzstan, Tajikistan, Azerbaijan, Singapore, Hongkong, Philippines, Indonesia, Thailand, myanmar, Laos, United Arab Emirates, Saudi Arabia, Palestine, Afghanistan, Bangladesh, Malaysia, Qatar , Lebanon, Armenia, Yemen, Jordan
America: Colombia, Chile, Suriname,Peru, Bolivia, Ecuador
Africa: Sudan, Cameroon, Algeria, Libya, Benin, Nigeria, Egypt, Ghana, Guinea, Mauritius, Kenya, Ethiopia, Cote d'ivoire, Tunisia
Europe: Serbia, Albania
Manufacturer Recommend:
|
|
| WNS Series Oil/Gas Fired Steam Boiler | DZL Series Coal/Biomass Fired Steam Boiler |
|
|
| YY(Q)W Series Oil/Gas Fired Thermal Oil Boiler | Electric Steam/Hot Water Boiler |
